G-162 Safety Sensors / Components
With Operation Key Inserted
D4NL + D4DS-K1
D4NL + D4DS-K3
D4NL + D4DS-K2
D4NL + D4DS-K5
Red
Black
(30.5)
(30.5)
(28.5)
Center
tolerance of
key hole: ± 1
44 min 46.5 max
Key insertion position
44 min 46.5 max
Key insertion position
Horizontal
insertion radius:
R ≥ 200
Vertical
insertion radius:
R ≥ 200
15
Center
tolerance of
key hole: ± 1
Red
Black
(30.5)
45 min 47.5 max
Key insertion position
(30.5)
45 min 47.5 max
Key insertion position
Horizontal
insertion radius:
R ≥ 50
Vertical
insertion radius:
R ≥ 200
Center
tolerance of
key hole: ± 1
40
±
0.15
Center
tolerance of
key hole: ± 1
(28.5)
Red
Black
(30.5)
40 min 42.5 max
Key insertion position
(30.5)
40 min 42.5 max
Key insertion position
Center
tolerance of
key hole: ± 1
15
Horizontal
insertion radius:
R ≥ 200
Vertical
insertion radius:
R ≥ 200
(6)
(22.5)
(28.5)
Center
tolerance of
key hole: ± 1
Red
Black
43
±0.1
(41
±0.1
)
(30.5)
20.9
5541
51.9 min 54.4 max
Key insertion position
Center
tolerance of
key hole: ± 1
Horizontal
insertion radius:
R ≥ 50
Vertical
insertion radius:
R ≥ 50
(30.5)
51.9 min 54.4 max
Key insertion position
Center
tolerance of
key hole: ± 1
(28.5)
