5
E3NC
Ratings and Specifications
Compact Laser Sensors: E3NC-L
Sensor Heads
*1. These Sensors are classified as Class 1 laser devices under IEC 60825-1 and the regulations of Laser Notice No. 50 for FDA certification. CDRH (Center for De-
vices and Radiological Health) registration has been completed.
E3NC-LH01, E3NC-LH02 (Accession Number: 1220690)
E3NC-LH03 (Accession Number: 1320739)
*2. The values were measured using the OMRON standard sensing object (white paper) for the E3NC-LH01, E3NC-LH02, and E3NC-LH02 + E39-P52.
The values for the E3NC-LH03, and E3NC-LH03 + E39-P51 apply when an E39-R21, E39-R22, E39-RS10, or E39-RS11 Reflector is used. Other Reflectors are
not recommended.
*3. Defined at the 1/e
2
(13.5%) of the central intensity at the measurement distance.
Measurement may be influenced if there is light leakage outside the defined region and the surroundings of the target object have a high reflectance in comparison
to the target object.
*4. Measured at the rated sensing distance.
*5. The E39-P5@ contains a packing to prevent entry of foreign matter. The degree of protection between the E3NC-LH@@ and E39-P5@ is not specified.
Sensing method
Coaxial Retro-reflective
with MSR function
Diffuse-reflective
Limited-
reflective
Item
Model E3NC-LH03
E3NC-LH03+
E39-P51
E3NC-LH02
E3NC-LH02+
E39-P52
E3NC-LH01
Light source (wavelength)*1
Visible semiconductor laser diode (660 nm), 1.35 mW (average output: 315 μW)
(JIS Class 1, IEC/EN Class 1, and FDA Class 1)
Sensing
distance*2
Giga-power mode
(GIGA)
8 m
0.5 m
1,200 mm 1,000 mm
70±15 mm
Standard mode (Stnd) 6 m 750 mm 600 mm
High-speed mode (HS) 3.5 m 250 mm 200 mm
Super-high-speed
mode (SHS)
2 m 200 mm 150 mm
Beam shape
Spot Line Spot Line Spot
Beam size*3
Approx. 2 mm dia.
at 1 m
Line length:
Approx. 25 mm at
250 mm
Line length:
Approx. 50 mm at
500 mm
Approx. 0.8 mm
dia. at 300 mm
Line length:
Approx. 45 mm at
500 mm
Line length:
Approx. 100 mm at
1,000 mm
Approx. 0.1 mm
dia. at 70 mm
Differential distance*4 --- 10% of sensing distance max.
Indicators OUT indicator (orange) and STABILITY indicator (green)
Ambient illumination (Receiver side)
Incandescent lamp: 10,000 lx max.,
Sunlight: 20,000 lx max.
Ambient temperature range Operating: −10 to 55°C; Storage: −25 to 70°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Altitude 2,000 m max.
Installation environment Pollution degree 3 (as per IEC 60947-1)
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 1,000 VAC at 50/60 Hz for 1 min
Vibration resistance (destruction) 10 to 55 Hz with a 1.5-mm double amplitude or 100 m/s
2
for 2 hours each in X, Y, and Z directions
Shock resistance (destruction) 500 m/s
2
for 3 times each in X, Y, and Z directions
Degree of protection IEC IP67*5
IEC IP65 (E3NC-LH02: Applies only when adjuster is
locked.)*5
Connecting method Pre-wired connector (standard length: 2 m)
Materials
Sensor
Head
Case Polybutylene terephthalate (PBT)
Lens Methacrylic resin (PMMA)
Cable Vinyl chloride (PVC)
Lens
Attachment
Case --- ABS --- ABS ---
Lens
---
Methacrylic resin
(PMMA)
---
Methacrylic resin
(PMMA)
---
Weight (packed
state/Sensor
Head only)
Models with 2-m cable Approx. 120 g/approx. 70 g Approx. 115 g/approx. 65 g
Models with 5-m cable Approx. 180 g/approx. 130 g Approx. 175 g/approx. 125 g
Lens Attachment
---
Approx. 25 g/
approx. 2 g
---
Approx. 25 g/
approx. 2 g
---
Accessories Instruction Manual
