E3NC
Amplifier Units
*1. Two sensor outputs are allocated in the programmable logic controller PLC I/O table.
PLC operation via Communications Unit enables reading detected values and changing settings.
*2. Applicable Sensor Head is the series of E3NC-LH@@ (Input/Output 10-30V DC Class 2)
*3. At Power Supply Voltage of 10 to 30 VDC.
Normal mode: 1,650 mW max. (Current consumption: 55 mA max. at 30 VDC, 115 mA max. at 10 VDC)
Eco ON: 1,410 mW max. (Current consumption: 47 mA max. at 30 VDC, 95 mA max. at 10 VDC)
Eco LO: 1,530 mW max. (Current consumption: 51 mA max. at 30 VDC, 105 mA max. at 10 VDC)
*4. The total for both outputs of a model with 2 outputs is 100 mA max. (Residual voltage: Load current of less than 10 mA: 1 V max., Load current of 10 to 100 mA: 2 V max.).
*5. The following details apply to the input.
*5-1.Input time is 25 ms (ON)/(OFF) only when (in tUnE) or (in PtUn) input is selected.
*6. The mutual interference prevention function is disabled if the detection mode is set to super-high-speed mode.
*7. When connected to an OMRON NJ-series Controller.
*8. The bank is not reset by the user reset function or saved by the user save function.
*9. Eco LO is supported for Amplifier Units manufactured in July 2014 or later.
Type Standard models
Model for Sensor
Communications Unit
NPN output E3NC-LA21 E3NC-LA7 E3NC-LA24
E3NC-LA0
PNP output E3NC-LA51 E3NC-LA9 E3NC-LA54
Item
Connecting method
Pre-wired Wire-saving Connector M8 Connector
Connector for Sensor
Communications Unit
Inputs/
outputs
Outputs 2 outputs 1 output
---
*1
External inputs 1 input
Power supply voltage *2 10 to 30 VDC, including 10% ripple (p-p)
Supplied from the connector
through the Sensor
Communications Unit
Power consumption *3
At Power Supply Voltage of 24 VDC
Normal mode: 1,560mW max. (Current consumption: 65mA max.)
Eco ON: 1,320 mW max. (Current consumption: 55 mA max.)
Eco LO: 1,440 mW max. (Current consumption: 60 mA max.)
Control outputs*4
Load power supply voltage: 30 VDC max., open-collector output
Load current: Groups of 1 to 3 Amplifier Units: 100 mA max., Groups of 4 to 30
Amplifier Units: 20 mA max.
OFF current: 0.1 mA max.
---
External inputs Refer to *5. ---
Indicators
7-segment displays (Sub digital display: green, Main digital display: white)
Display direction: Switchable between normal and reversed.
OUT indicator (orange), L/D indicator (orange), ST indicator (blue), DPC indicator (green), and OUT selection
indicator (orange, only on models with 2 outputs)
Protection circuits
Power supply reverse polarity protection, output short-circuit protection, and
output reverse polarity protection
Power supply reverse polarity
protection and output short-
circuit protection
Response
time
Super-high-speed mode (SHS)*6 Operate or reset: 80 μs
High-speed mode (HS) Operate or reset: 250 μs
Standard mode (Stnd) Operate or reset: 1 ms
Giga-power mode (GIGA) Operate or reset: 16 ms
Sensitivity adjustment
Smart Tuning (2-point tuning, full auto tuning, position tuning, maximum sensitivity tuning, power tuning, or
percentage tuning (−99% to +99%)), or manual adjustment.
Maximum connectable Units 30
With E3NW-ECT: 30 units
*7
With E3NW-CRT: 16 units
With E3NW-CCL: 16 units
No. of Units
for mutual
interference
prevention
Super-high-speed mode (SHS)*6 0
High-speed mode (HS) 2
Standard mode (Stnd) 2
Giga-power mode (GIGA) 4
Functions
Dynamic power control (DPC) Provided
Timer Select from timer disabled, OFF-delay, ON-delay, one-shot, or ON-delay + OFF-delay timer: 1 to 9,999 ms
Zero reset Negative values can be displayed. (Threshold value is shifted.)
Resetting settings*8 Select from initial reset (factory defaults) or user reset (saved settings).
Eco mode*9 Select from OFF (digital display lit), ECO ON (digital display not lit), and ECO LO (digital display dimmed).
Bank switching Select from banks 1 to 4.
Power tuning Select from ON or OFF.
Output 1 Select from Normal Detection Mode or Area Detection Mode.
Output 2
Select from normal detection
mode, alarm output mode,
or error output mode.
---
Select from normal detection
mode, alarm output mode, or
error output mode.
External input
Select from input OFF, tuning, power tuning, laser OFF, zero reset, or bank switching.
---
Hysteresis width Select from standard setting or user setting.
Contact input (relay or switch) Non-contact input (transistor) Input time*
5-1
NPN
ON: Shorted to 0 V (Sourcing current: 1 mA max.).
OFF: Open or shorted to Vcc.
ON: 1.5 V max. (Sourcing current: 1 mA max.)
OFF: Vcc − 1.5 V to Vcc (Leakage current: 0.1 mA max.)
ON: 9 ms min.
OFF: 20 ms min.
PNP
ON: Shorted to Vcc (Sinking current: 3 mA max.).
OFF: Open or shorted to 0 V.
ON: Vcc − 1.5 V to Vcc (Sinking current: 3 mA max.)
OFF: 1.5 V max. (Leakage current: 0.1 mA max.)
Residual voltage:
At load current of less than 10 mA: 1 V max.
At load current of 10 to 100 mA: 2 V max.
