F3W-E
4
Engineering Data (Typical)
Parallel Operating Range Angle Characteristic
Tilt Rotation
Distance X (mm)
Distance Y (mm)
150
100
50
0
−50
−100
−150
100 200 300 400 500
1
2
Distance X (mm)
20
15
10
5
0
−5
−10
−15
−20
100 200 300 400 500
1
2
Angle θ (°)
Distance X (mm)
80
60
40
20
0
−20
−40
−60
−80
100 200 300 400 500
1
2
Angle θ (°)
X
Y
X
Y
1. Horizontal Movement
Characteristics
2. Vertical Movement
Char
acteristics
X
θ
X
θ
or
X
X
θ
θ
or
Tilt TiltRotation Rotation
1. Emitter Angle
Characteristics
2. Receiver Angle
Characteristics
