16
E3MCE3MC
Accessories (Order Separately) (2-m Cord is Provided with the E3MC)
E3MC-Y@@
E3MC-MY@@
M12 connector
Four, M5 holes (depth: 5.5)
Side Mounting
Bottom Mounting
Two, M2.6 x 6
Two, 5.5-dia. holes
Four, 5.5-dia. holes
Two, 2.4 dia.
Receiver section
Emitter section
Fiber Unit mounting screw
Four, M5 holes on both
sides (depth: 5.5)
Mounting Dimensions
(Amplifier Unit)
Sensor I/O Connector
E39-C1 2M: 2 m*
E39-C1 5M: 5 m*
6 dia.
8.8 dia.
10.5 dia.
L*
Sensor Mounting Bracket
Emitter
Optical sensing axis
Receiver
When using the E3MC-@X
Mounting Bracket
Mounting Dimensions
Six, R2.6
Four, M5
Four, M5
Material: Stainless steel (SUS430)
E39-L114
