A - 47
A Appendices
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific
Objects
To set tuning information to a different amplifier (CA0 only)
• If you want to copy tuning information to another amplifier, read the index below in the original
amplifier and write the information that is read to the other amplifier.
Write all index number items in the table below that apply to the detection method in order.
* Tuning information cannot be set for output 2. For details, see the detection method selection item (Index 4038 +
(N - 1) × 80 Hex).
• If you want to set tuning information to a different amplifier, use this index.
• If you want to set tuning information to a different amplifier, use this index.
* is supported from E3NW-ECT Ver 1.08
• The External input detection time range for the VD□0 is 5 to 9999 ms.
• If you want to set tuning information to a different amplifier, use this index.
• If you want to set tuning information to a different amplifier, use this index.
Index No Name
Detection method
Contrast Color
4038+(N-1)×80 hex Detection method selection 1st 1st
400B+(N-1)×80 hex Detection function 2nd 2nd
4064+(N-1)×80 hex Tuning setting (1) 3rd 3rd
4065+(N-1)×80 hex Tuning setting (2) 4th 4th
4066+(N-1)×80 hex Tuning setting (3) Not applicable 5th
4067+(N-1)×80 hex Tuning setting (4) Not applicable 6th
4068+(N-1)×80 hex Tuning setting (5) Not applicable 7th
4004+(N-1)×80 hex Threshold 1 setting 5th 8th
4005+(N-1)×80 hex Threshold 2 setting 6th 9th
4064 + (N-1) × 80
hex
No_01 ... 30 Tuning Setting (1)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Tuning Setting (1)
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
4065 + (N-1) × 80
hex
No_01 ... 30 Tuning Setting (2)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Tuning Setting (2)
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
4066 + (N-1) × 80
hex
No_01 ... 30 Tuning Setting (3) External input detection time*
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Tuning Setting (3)
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 4 bytes (U32) Access: RW PDO map: Not possible
4067 + (N-1) × 80
hex
No_01 ... 30 Tuning Setting (4)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Tuning Setting (4)
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 4 bytes (U32) Access: RW PDO map: Not possible
