2 - 3
2 EtherCAT Sensor Communication Unit
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
2-2 Connectable Sensor Amplifiers
2
2-2-1 List of Sensor Amplifiers
2-2 Connectable Sensor Amplifiers
This section explains the types of connectable sensor amplifiers with EtherCAT Sensor Communication
Units.
* The E9NC-TA0 is supported from E3NW-ECT Ver 1.03. The E3NX-CA0 is supported from E3NW-ECT Ver 1.06.
The E3NX-MA0, E2NC-EA□0, E9NC-AA□0/VA□0/VD□0 are supported from E3NW-ECT Ver 1.08 of the
E3NW-ECT. You can check the version with object index 100A hex. (Refer to "A-1-4 Communication Objects" on
page A-4.)
This Sensor Communication Unit allows you to connect up to 30 Sensor Amplifiers, including those that
are connected to the Distributed Sensor Units.
You can connect up to 10 Sensors to a Distributed Sensor Unit.
You can connect up to eight Distribution Sensor Units in one Sensor Communication Unit.
* Also refer to the Sensor Amplifier specifications, as the number of connected units varies depending on the
Sensor Amplifier specifications.
2-2-1 List of Sensor Amplifiers
Name Model Features
Smart Fiber Amplifiers E3NX-FA□0 These standard fiber amplifiers are easy to use and set up.
Smart Laser Amplifier Unit E3NC-LA0
These laser sensors use a minute spot and yet they provide
stable detection.
Smart Laser Amplifier Unit
(CMOS Type)
E3NC-SA0
These laser sensors use a CMOS device that allows reliable
detection of stepped surfaces.
Contact-type Smart Sensors E9NC-TA0 These contact-type sensors are durable.
Color fiber amplifier E3NX-CA0 Fiber amplifier with color sensing for stable detection
Smart Fiber Amplifiers E3NX-MA0 Fiber Amplifier with Light Emission/Reception
Smart Fiber Amplifiers E3NX-FAH0 Fiber Amplifier with Near Infrared Light Emission/Reception
Smart Amplifier Separation
Proximity Unit
E2NC-EA□0 Proximity Sensor Amplifier
Smart Analog Input Unit E9NC-AA□0 Current (4 to 20 mA) Input Amplifier
Smart Analog Input Unit E9NC-VA□0 Voltage (1 to 5 V) Input Amplifier
Smart Analog Input Unit E9NC-VD□0 Voltage Differential Input (−2 to 2V), Input Type
2-2-2 Number of Connected Sensor Amplifiers
