E3X-SD/-NA
19
Amplifier Unit Connectors
Accessories (Order Separately)
For information on Fiber Units, refer to the E32 Series Fiber Sensor Best Selection (Cat. No. E353).
Master Connector
E3X-CN11
(7)
2,000
+50
0
*
* E3X-CN11: 4 dia.
4 dia.
cable / 3 conductors
3 conductors
/ Standard length: 2 m (Conductor cross section: 0.2 mm
2
(AWG24), Insulator diameter: 1.1 mm)
Edge of amplifier
Slave Connector
E3X-CN12
(7)
2,000
+50
0
*
* E3X-CN12: 2.6 dia.
2.6 dia.
cable / 1 conductor
1 conductor
/ Standard length: 2 m (Conductor cross section: 0.2 mm
2
(AWG24), Insulator diameter: 1.1 mm)
Edge of amplifier
Mounting Brackets
E39-L143
Four, R1.7
7
3.4
1
3163
10 max. 710.3
7.3
5.3
(10.3)
2.5
34.8
22
16
26.8
3
Two, 3.2 dia.
3.4
1
Two, M3
16
±0.1
Mounting Holes
Material: Stainless steel
(SUS304)
End Plates
PFP-M
50
11.5
10
M4 × 8
panhead screw
M4 spring washer
4.8
1.3
1.8
1.8
1
6.2
10
35.5
35.3
