Precision
700 mm
3 m
Distance
14 m
Super-long-distance
Fiber Unit
E32-T17L
Standard Fiber Unit +
Long-distance Lens
E32-TC200+E39-F1
Long-distance Fiber Unit
E32-T11L
The three most important performance
capabilities when selecting a sensor are
achieved to a high standard: distance, speed,
and precision.
A balance is provided between reliable
detection performance and capability for a
broad range of applications.
3
Distance
Speed
General-purpose Performance for Simple Use
Optical communications is used between Amplifiers.
Interference is reliably prevented for up to five Amplifiers by mutually staggering the light emission timing
(except for the E3X-NA@F).
4
Optical Communications to Prevent Mutual Interference for Up to Five Amplifiers
400 mm
Standard Fiber Unit
E32-TC200
Sufficient distance performance.
A maximum distance of 14 m
can be achieved by using a
Long-distance Fiber Unit
(through-beam) in combination
with the Amplifier.
Gold wire with a diameter of 30 µm can
be detected.
And minute workpieces can be detected.
Note: The diameter of 30 µm is a typical value
when the sensing distance and sensitivity are
set to their optimal conditions.
The response speed handles 2,500
counts per second to enable detecting
high-speed workpieces
(25,000 counts per second for the E3X-NA@F).
High-speed response of 200 µm
and reliable interference
prevention for up to five Amplifiers
Up to
five Amplifiers
Balanced
application capabilities
E3X-SD
High-speed Models
Long-distance Models
2,500 counts/second
30-µm dia.
200 µs
Optical communications
Simplicity and High Performance
