Sensing Distance
Through-beam Models (Unit: mm)
Model
E3X-SD@
E3X-NA@
E3X-NA@F
Type
Standard
models
High-speed detection
models
Standard
models
Flexible
(new standard)
E32-T11R/E32-T12R/E32-T15XR/E32-TC200BR (B4R) 280 80
E32-T14LR/E32-T15YR/E32-T15ZR 110 33
E32-T21R/E32-T22R/E32-T222R/E32-T25XR/
E32-TC200FR (F4R)
60 18
E32-T24R/E32-T25YR/E32-T25ZR 30 9
Standard
E32-TC200/E32-T12/E32-T15X/E32-TC200B (B4) 400 120
E32-T14L/E32-T15Y/E32-T15Z 240 70
E32-TC200A 360 100
E32-TC200E/E32-T22/E32-T222/E32-T25X/E32-TC200F (F4) 100 30
E32-T24/E32-T25Y/E32-T25Z 90 27
Break resistant
E32-T11/E32-T12B/E32-T15XB 360 100
E32-T21/E32-T221B/E32-T22B 100 30
E32-T25XB 75 20
Fluorine coating E32-T11U 360 100
Special-
beam
models
Long distance,
high power
E32-T17L 14000 4200
E32-TC200 + E39-F1 3000 900
E32-T11R + E39-F1 2100 630
E32-T11 + E39-F1 2000 600
E32-T14 1800 540
E32-T11L/E32-T12L 700 210
E32-T11L + E39-F2 500 150
E32-T11R + E39-F2 220 65
E32-T11 + E39-F2 360 100
E32-T21L/E32-T22L 200 60
Ultracompact,
ultrafine sleeve
E32-T223R 60 18
E32-T33-S5 20 6
E32-T333-S5 5 1.5
E32-T334-S5 2.5 0.8
Fine beam
(narrow vision field)
E32-T22S 1000 300
E32-T24S 700 210
Area sensing
E32-T16PR 450 130
E32-T16P 600 180
E32-T16JR 390 110
E32-T16J 520 150
E32-T16WR 690 200
E32-T16W 920 270
E32-T16 1500 450
E32-M21 300 90
Environment
resistive
models
Heat resistant
E32-T51 400 120
E32-T54 130 35
E32-T81R-S 180 50
E32-T61-S + E39-F2 390 130
E32-T61-S + E39-F1 3000 900
E32-T84S-S 700 210
E32-T61-S 300 90
Chemical
resistant
E32-T11F 1050 380
E32-T12F 1600 480
E32-T14F 200 60
E32-T51F 700 200
E32-T81F-S 350 100
Vacuum
resistant
E32-T51V 100 ---
E32-T51V + E39-F1V 600 ---
E32-T54V 65 ---
E32-T54V + E39-F1V 390 ---
E32-T84SV 250 ---
For information on Fiber Units, refer to the E32 Series Fiber Sensor Best Selection (Cat. No. E354).
