A-52 Standard Photoelectric Sensors
Rating/performance
Sensor type Through-beam Retroreflective
model (with
M.S.R. func-
tion)
Diffuse-reflective
wide-beam standard-beam
Model
NPN output
E3Z-T62/T67 E3Z-T61/T66 E3Z-T61A/T66A E3Z-R61/R66 E3Z-D61/D66 E3Z-D62/D67
Item PNP output E3Z-T82/T87 E3Z-T81/T86 E3Z-T81A/T86A E3Z-R81/R86 E3Z-D81/D86 E3Z-D82/D87
Vibration resistance 10 to 55 Hz, 1.5-mm or 300m/s
2
double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance Destruction: 500 m/s
2
for 3 times each in X, Y, and Z directions
Protective structure IEC 60529 IP67, IP69k after DIN 40050 part 9
Connection method Pre-wired (standard length: 2 m/500 mm)/M8 connector
Indicator lamp Operation indicator (orange), stability indicator (green) [Note that the emitter has the power indicator
(orange) only]
Weight
(Packed
state)
Pre-wired
models (with
2-m cable)
Approx. 120 g 65 g
Connector type 30 g Approx. 20 g
Material Case PBT (polybutylene terephthalate)
Lens Denatured poly-
acrylate resin
Methacylate resin
Accessories Instruction manual (The Reflector or Mounting Bracket is not provided with any of the above models.)
