E3Z
Rating/performance
Diffuse-
reflective
Distance-
settable
Retro-reflective for PET bottles
(without MSR function)
Grooved-type
narrow-beam standard-beam wide-beam
E3Z-L61/66 E3Z-LS61/66 E3Z-B61/66 E3Z-B62/67 E3Z-G61 E3Z-G62
E3Z-L81/86 E3Z-LS81/86 E3Z-B81/86 E3Z-B82/87 E3Z-G81 E3Z-G82
90 ± 30 mm
(White paper
100 x 100 mm)
BGS: White or black paper (100 x 100 mm):
20 mm to set distance
FGS: White paper (100 x 100 mm):
Set distance to 200 mm min.
Black paper (100 x 100 mm): Set distance to
160 mm min.
500 mm
(80 mm) *
(When using the
E39-R1S)
2 m (100 mm) *
(When using the
E39-R1S)
25 mm
1 optical axis 2 optical axis
--- White paper (100 x 100 mm): 40 to 200 mm
Black paper (100 x 100 mm): 40 to 160 mm
---
Refer to
the diagram
„Hysteresis
Difference vs.
Sensing
Distance“
Black/white-error:
10% of set distance max.
---
2.5 mm dia.
(when sensing
distance is
90 mm)
---
--- Transparent round PET bottle
500 ml (65 mm dia.)
---
0.1 mm dia.
(copper wire)
---
---
Red LED
(650 nm)
Red LED
(680 nm)
Red LED
(660 nm)
Infrared LED
(860 nm)
12 to 24 VDC ±10%, ripple (p-p) : 10% max.
30 mA max 25 mA max. 40 mA max.
Load power supply voltage 26.4 VDC max., load current 100 mA max. (residual voltage 2 V max.) Open collector output type
(depends on the NPN/PNP output format) Light-ON/Dark-ON switch selectable
--- BGS: Open or connected to GND
FGS: Connected to Vcc
---
Reverse polarity protection, output short-circuit protection, mutual interference prevention
Operation or reset: 1 ms max.
Single-turn
adjustment
five-turn endless adjuster Single-turn adjustment ---
Incandescent lamp: 3,000 lux max. Sunlight 10,000 lux max.
Operating: -25°C to 55°C, Storage: -40°C to 70°C (with no icing or condensation)
Operating: 35% to 85% RH, Storage: 35% to 95% RH (with no icing or condensation)
20 M min. at 500 VDC
1,000 VAC at 50/60 Hz for 1 minute
