E4 English
14
Product Name OMRON E4 TENS massager
Model HV-F128-E
Power supply 3 VDC (2 1.5V alkaline batteries type AAA LR03)
Battery life Approx. 3 months: when used 15 minutes a day continuously
Approx. 2 months: when used 15 minutes a day continuously
under Hyper mode
Frequency generation Approx. 1 to 1200 Hz
Power consumption Approx. 85 mA
Maximum Output Voltage U ≤ 90 V (during 1 kΩ load)
Maximum Output Current I ≤ 10 mA (during 1 kΩ load)
Operating temperature and humidity 10°C to 40°C, 30 to 85% RH
Storage temperature and humidity -20°C to 60°C, 10 to 95% RH
Main unit dimensions 60 (W) x 199 (H) x 21 (D) mm
Weight Approx. 155 g (including batteries)
Package Contents Electrode cord
Set of Long Life pads
Batteries for monitor (2 identical 1.5V alkaline batteries type AAA LR03)
Long Life pad holder
Soft fabric case
Instruction manual
9. Technical Data
Disposal of this product and used batteries
should be carried out in accordance with
the national regulations for the disposal of
electronic products.
This product should not be used by persons
with medical implants, e.g. heart
pacemakers, artificial heart, lung or other
electronic life support systems.
Specifications may be changed without prior notice.
Available accessories / replacement parts:
1. Electrode Pads (Long Life Pads) with holder order no. 4928818-7
2. Electrode Cord (with safety plug) order no. 3027801-6
3. Electrode Pad Holder order no. 1614950-5
Type BF
Read the instructions in this manual
carefully.
This device fulfils the provisions of the EC directive 93/42/EEC (Medical Device Directive).
This OMRON product is produced under the strict quality system of OMRON HEALTHCARE Co., Ltd., Japan.
