Omron E5AC User Manual

5 Advanced Operations
5 - 54
E5@C Digital Temperature Controllers User’s Manual (H174)
This procedure sets the MV change rate limit to 5.0%/s. The related
parameters are as follows:
PID ON/OFF = PID
ST = OFF
Operating Procedure
• Setting 2-PID Control
1 Press the M Key several times in the Initial Setting Level to
display cntl (PID ON/OFF).
Initial Setting Level
2 Press the U or D Key to select pid (PID).
The default is onof (ON/OFF control).
• Turning OFF Self-tuning
1 Press the M Key several times in the Initial Setting Level to
display st (ST: self-tuning).
Initial Setting Level
2 Press the U or D Key to set the value to off.
The default is on.
• Setting the MV Change Rate Limit
1 Press the M Key several times in the Adjustment Level to dis-
play orl (MV Change Rate Limit).
Adjustment Level
2 Press the U or D Key to set the value to 5.0.
The default is 0.0 (%/s).
onof
cntl
PID ON/OFF
pid
cntl
on
st
ST
off
st
0.0
orl
MV Change
Rate Limit
5.0
orl

Omron E5AC Specifications

General

Mounting Type	Panel Mount
Sampling Period	50 ms
Protection structure	IP66 (front panel)
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Control Output	Relay, voltage, current
Dimensions	96 x 96 mm
Display Type	LCD
Number of Displays	2
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
