Omron E5AC User Manual

A Appendices
A - 26
E5@C Digital Temperature Controllers User’s Manual (H174)
A-6-2 Adjustment Level
Parameters Characters Setting (monitor) value Display Default Unit
Adjustment Level
Display
l.adj
AT Execute/Cancel at OFF, AT Cancel
AT-2: 100%AT Execute
AT-1: 40%AT Execute
*1
off, at-2,
at-1
OFF None
Communications
Writing
cmwt OFF, ON
off, on
OFF None
SP Mode
spmd LSP, RSP
lsp, rsp
LSP None
Heater Current 1 Value
Monitor
ct1 0.0 to 55.0 A
Heater Burnout
Detection 1
hb1 0.0 to 50.0 0.0 A
Heater Current 2 Value
Monitor
ct2 0.0 to 55.0 A
Heater Burnout
Detection 2
hb2 0.0 to 50.0 0.0 A
Leakage Current 1
Monitor
lcr1 0.0 to 55.0 A
HS Alarm 1 hs1 0.0 to 50.0 50.0 A
Leakage Current 2
Monitor
lcr2 0.0 to 55.0 A
HS Alarm 2
hs2 0.0 to 50.0 50.0 A
SP 0 sp-0 SP lower limit to SP upper limit 0 EU
SP 1 sp-1 SP lower limit to SP upper limit 0 EU
SP 2 sp-2 SP lower limit to SP upper limit 0 EU
SP 3 sp-3 SP lower limit to SP upper limit 0 EU
SP 4 sp-4 SP lower limit to SP upper limit 0 EU
SP 5 sp-5 SP lower limit to SP upper limit 0 EU
SP 6 sp-6 SP lower limit to SP upper limit 0 EU
SP 7 sp-7 SP lower limit to SP upper limit 0 EU
Process Value Input
Shift
ins Temperature input: −199.9 to 999.9 0.0 °C or °F
Analog input: −1,999 to 9,999 0 EU
Process Value Slope
Coefficient
inrt 0.001 to 9.999 1.000 None
Remote SP Input Shift rss Temperature input: −199.9 to 999.9 0.0 °C or °F
Analog input: −1,999 to 9,999 0 EU
Remote SP Input
Slope Coefficient
rsrt 0.001 to 9.999 1.000 None
Proportional Band p Temperature input: 0.1 to 999.9 8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
Integral Time
i Standar
d, heating/cooling, or close
position-proportional control:
Integ
ral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to
999.9
Floating position-proportional control:
Integral/Derivative Time Unit of 1 s: 1 to 9999
Integral/Derivative Time Unit of 0.1 s: 0.1 to
999.9
233
233.0
Seconds
Derivative Time d Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
40
40.0
Seconds
Proportional Band
(Cooling)
c-p Temperature input: 0.1 to 999.9 8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
000
000
000
000
000
000
000
000
000

Omron E5AC Specifications

General

Mounting Type	Panel Mount
Sampling Period	50 ms
Protection structure	IP66 (front panel)
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Control Output	Relay, voltage, current
Dimensions	96 x 96 mm
Display Type	LCD
Number of Displays	2
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
