Omron E5AC User Manual

6 - 57
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-7 Initial Setting Level
6
eV-1
Event Input Assignment 1
eV-2
Event Input Assignment 2
eV-3
Event Input Assignment 3 There must be event inputs.
eV-4
Event Input Assignment 4
eV-5
Event Input Assignment 5
eV-6
Event Input Assignment 6
• The following functions can be assigned to event inputs 1 to 6.
RUN/STOP
Auto/Manual Switch
Program Start
Invert Direct/Reverse Operation
SP Mode Switch
100% AT Execute/Cancel
40% AT Execute/Cancel
Setting Change Enable/Disable
Communications Writing Enable/Disable
Alarm Latch Cancel
Multi-SP No. Switching Bit 0
Multi-SP No. Switching Bit 1
Multi-SP No. Switching Bit 2
000
000
Function
• Default:
Event Input Assignment 1: msp0
Event Input Assignment 2: stop
Event Input Assignment 3: none
Event Input Assignment 4: none
Event Input Assignment 5: none
Event Input Assignment 6: none
• Do not assign the same function to more than one event input.

Omron E5AC Specifications

General

Mounting Type	Panel Mount
Sampling Period	50 ms
Protection structure	IP66 (front panel)
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Control Output	Relay, voltage, current
Dimensions	96 x 96 mm
Display Type	LCD
Number of Displays	2
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
