Omron E5AC User Manual

1 - 9
1 Introduction
E5@C Digital Temperature Controllers User’s Manual (H174)
1-2 I/O Configuration and Model
Number Legend
1
1-2-2 Model Number Legends
 E5EC/AC (Models with Screw Terminal Blocks)
*1 The options that can be selected depend on the type of control output.
*2 The control output cannot be used as a simple transfer output.
*3 These cannot be selected if 5 (screw terminals with cover) is selected for the terminal type.
(1) (2) (3) (4) (5) (6) (7) Meaning
E48 × 96 mm
A96 × 96 mm
Control output 1 Control output 2
*1 R X Relay output None
*1 Q X Voltage output (for driving SSR) None
*2*1 C X Linear current output None
*1 Q Q Voltage output (for driving SSR) Voltage output (for driving SSR)
*1 Q R Voltage output (for driving SSR) Relay output
*1 R R Relay output Relay output
*2*1 C C Linear current output Linear current output
*2*1 C Q Linear current output Voltage output (for driving SSR)
*1 P R Position-proportional relay output Position-proportional relay output
*3 2 2
44
A 100 to 240 VAC
D 24 VAC/DC
S Screw terminals
5 Screw terminals (with cover)
M Universal input
Event
inputs
Communications
Remote
SP Input
HB alarm
and HS
alarm
Transfer
output
For RX,
QX, RR,
QQ, QR,
or CQ
For CX or
CC
For PR
000 --- --- --- --- --- Selectable Selectable Selectable
004 2 RS-485 --- --- --- --- Selectable Selectable
005 4 --- --- --- --- --- Selectable ---
*3 008 2 RS-485 --- 1 --- Selectable --- ---
009 2 RS-485 --- 2 (for
3-phase
heaters)
--- Selectable --- ---
010 4 --- --- 1 --- Selectable --- ---
011 6 --- Provided. 1 Provided. Selectable --- ---
*3 012 4 RS-485 Provided. 1 Provided. Selectable --- ---
013 6 --- Provided. --- Provided. --- Selectable ---
014 4 RS-485 Provided. --- Provided. --- Selectable Selectable
-- -
E5 C
- -
(1) (2) (3) (4) (5) (6) (7)
Size
Control Outputs 1 and 2
No. of auxiliary outputs
Power supply voltage
Terminal type
Input type
Options

Omron E5AC Specifications

General

Mounting Type	Panel Mount
Sampling Period	50 ms
Protection structure	IP66 (front panel)
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Control Output	Relay, voltage, current
Dimensions	96 x 96 mm
Display Type	LCD
Number of Displays	2
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
