Omron E5AC User Manual

6 - 75
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-8 Advanced Function Setting Level
6
amad
Auto/Manual Select Addition Control must be set to 2-PID control.
• This parameter sets whether the Auto/Manual Select Addition parameter is to be
displayed.
 Related Parameters
Auto/Manual Switch (Operation Level): Page 6-9
mant
Manual Output Method
Control must be set to 2-PID control.
A Position-proportional Model set to Close Control
with the Direct Setting of Position-proportional MV
parameter set to ON must be used.
If this parameter is set to HOLD when control moves from Automatic Mode to Manual Mode,
the final MV from Automatic Mode will be used as the initial manual MV. If this parameter is
set to INT, the setting of the Manual MV Initial Value parameter will be used as the initial
manual MV.
 Related Parameters
Manual MV Initial Value (Advanced Function Setting Level): 6-76
Function
Setting
Setting range Default
on: Displayed, off: Not displayed Standard Model: off
Position-proportional Model: on
See
See
Function
Setting
Setting range Default
hold: HOLD, init: INIT hold
See
See

Omron E5AC Specifications

General

Mounting Type	Panel Mount
Sampling Period	50 ms
Protection structure	IP66 (front panel)
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Control Output	Relay, voltage, current
Dimensions	96 x 96 mm
Display Type	LCD
Number of Displays	2
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
