Omron E5AN Communications Manual

Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-3
Note 1: Not displayed on the Controller display.
Note 2: In 2-byte mode, the rightmost 16 bits are read.
Note 3: In 2-byte mode, the leftmost 16 bits are read.
Address
Parameter name Setting (monitor) value LevelFour-
byte
mode
Two-
byte
mode
010E 2107 Alarm Value 2 H'FFFFF831 to H'0000270F (−1999 to 9999) Operation
0110 2108 Alarm Value Upper Limit 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
0112 2109 Alarm Value Lower Limit 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
0404 2402 PV Temperature: Use the specified range for each sensor.
Analog: Scaling lower limit − 5% FS to Scaling upper limit +
5% FS
0406 2403 Internal Set Point (See note 1.) SP lower limit to SP upper limit
0408 2404 Multi-SP Monitor H'00000000 to H'00000003 (0 to 3)
040C 2406 Status (See notes 1 and 2.) See the 6.2 Status and status 2 for details.
040E 2407 Status (See note 3.) See the 6.2 Status and status 2 for details.
0410 2408 Status 2 (See notes 1 and 2.) See the 6.2 Status and status 2 for details.
0412 2409 Status 2 (See notes 1 and 3.) See the 6.2 Status and status 2 for details.
0420 2410 Decimal Point Monitor H'00000000 to H'00000003 (0 to 3)
0422 2411 Control Output 1 ON/OFF
Count Monitor
H'00000000 to H'0000270F (0 to 9999) Advanced
function
setting
0424 2412 Control Output 2 ON/OFF
Count Monitor
H'00000000 to H'0000270F (0 to 9999)
0500 2500 Operation/Adjustment Protect H'00000000 (0): No restrictions in operation and adjust-
ment levels
H'00000001 (1): Move to adjustment level is prohibited.
H'00000002 (2): Display and change of only “PV” and
“PV/SP” parameters is allowed.
H'00000003 (3): Display of only “PV” and “PV/SP”
parameters is allowed.
Protect
0502 2501 Initial Setting/Communications
Protect
H'00000000 (0): Move to initial setting/communications
setting level is allowed. (Move to
advanced function setting level is dis-
played.)
H'00000001 (1): Move to initial setting/communications
setting level is allowed. (Move to
advanced function setting level is not
displayed.)
H'00000002 (2): Move to initial setting/communications
setting level is prohibited.
0504 2502 Setting Change Protect H'00000000 (0): OFF (Changing of setup on controller
display is allowed.)
H'00000001 (1): ON (Changing of setup on controller
display is prohibited.)
0506 2503 PF Key Protect H'00000000 (0): OFF
H'00000001 (1): ON
0508 2504 Move to Protect Level H'FFFFF831 to H'0000270F (−1999 to 9999)
050A 2505 Password to Move to Protect
Level
H'FFFFF831 to H'0000270F (−1999 to 9999)
(Can only be set. The monitor value is always H’00000000.)
050C 2506 Parameter Mask Enable H'00000000 (0): OFF
H'00000001 (1): ON
