SECTION 6 Communications Data for Modbus
6-4
Address
Parameter name Setting (monitor) value LevelFour-
byte
mode
Two-
byte
mode
0600 2600 Manual MV Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A
(−105.0 to 105.0)
Manual
control
0602 2601 Set Point SP lower limit to SP upper limit Operation
0608 2604 Heater Current 1 Value
Monitor
H'00000000 to H'00000226 (0.0 to 55.0)
060A 2605 MV Monitor (Heating) Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'00000000 to H'0000041A
(0.0 to 105.0)
060C 2606 MV Monitor (Cooling) H'00000000 to H'0000041A (0.0 to 105.0)
0700 2700 Cooling Coefficient H'00000001 to H'0000270F (0.01 to 99.99) Adjustment
0708 2704 Dead Band H'FFFFF831 to H'0000270F
(−199.9 to 999.9 for TC/Pt universal input models)
(−19.99 to 99.99 for Analog input models)
070A 2705 Manual Reset Value H'00000000 to H'000003E8 (0.0 to 100.0)
070C 2706 Hysteresis (Heating) H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
070E 2707 Hysteresis (Cooling) H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
0710 2708 Control Period (Heating) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
Initial set-
ting
0712 2709 Control Period (Cooling) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
0718 270C SP Ramp Time Unit H'00000000 (0): EU/second
H'00000001 (1): EU/minute
H'00000002 (2): EU/hour
Advanced
function
setting
071A 270D SP Ramp Set Value H'00000000 (0): OFF
H'00000001 to H'0000270F (1 to 9999)
Adjustment
071E 270F MV at Stop Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A (−105.0 to
105.0)
0722 2711 MV at PV Error Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6to H'0000041A (−105.0 to
105.0)
0726 2713 MV Change Rate Limit H'00000000 to H'000003E8 (0.0 to 100.0)
072C 2716 Lower Limit Temperature
Input Shift Value
H'FFFFF831 to H'0000270F (−199.9 to 999.9)
0730 2718 Upper Limit Temperature
Input Shift Value
H'FFFFF831 to H'0000270F (−199.9 to 999.9)
0734 271A Heater Current 1 Value
Monitor
H'00000000 to H'00000226 (0.0 to 55.0) Operation
0736 271B Heater Burnout Detec-
tion 1
H'00000000 to H'000001F4 (0.0 to 50.0) Adjustment
0738 271C Leakage Current 1 Moni-
tor
H'00000000 to H'00000226 (0.0 to 55.0) Operation
