Omron E5AN Communications Manual

Com Data
for Modbus
SECTION 6 Communications Data for Modbus
6-6
Note: The alarm function can also be used in Controllers without alarm output terminals. In this case,
confirm alarm occurrences via the status data.
Note 1: Not displayed on the Controller display when Alarm 3 is not assigned to the output.
Address
Parameter name Setting (monitor) value LevelFour-
byte
mode
Two-
byte
mode
0800 2800 Input Digital Filter H'00000000 to H'0000270F (0.0 to 999.9) Advanced
function
setting
0810 2808 Extraction of Square Root
Low-cut Point
H'00000000 to H'000003E8 (0.0 to 100.0) Adjustment
0900 2900 SP 0 SP lower limit to SP upper limit
0904 2902 Alarm Value 1 H'FFFFF831 to H'0000270F (−1999 to 9999) Operation
0906 2903 Alarm Value Upper Limit 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
0908 2904 Alarm Value Lower Limit 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
090A 2905 Alarm Value 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
090C 2906 Alarm Value Upper Limit 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
090E 2907 Alarm Value Lower Limit 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
0910 2908 Alarm Value 3 (See note
1.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
0912 2909 Alarm Value Upper Limit 3
(See note 1.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
0914 290A Alarm Value Lower Limit 3
(See note 1.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
091C 290E SP 1 SP lower limit to SP upper limit Adjustment
0938 291C SP 2 SP lower limit to SP upper limit
0954 292A SP 3 SP lower limit to SP upper limit
0A00 2A00 Proportional Band H'00000001 to H'0000270F (0.1 to 999.9)
0A02 2A01 Integral Time H'00000000 to H'00000F9F (0 to 3999)
0A04 2A02 Derivative Time H'00000000 to H'00000F9F (0 to 3999) (Range when RT is
“OFF.”)
H'00000000 to H'0000270F (0.0 to 999.9) (Range when RT is
“ON.”)
0A0A 2A05 MV Upper Limit Standard: MV lower limit + 0.1 to H’0000041A (MV lower limit
+ 0.1 to 105.0)
Heating and cooling: H'00000000 to H'0000041A (0.0 to
105.0)
0A0C 2A06 MV Lower Limit Standard: H’FFFFFFCE to MV upper limit − 0.1 (−5.0 to MV
upper limit − 0.1)
Heating and cooling: H'FFFFFBE6 to H'00000000
(−105.0 to 0.0)
