Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-7
Note: The input type can be selected to match the connected sensor.
There are two input type specifications: Thermocouple/Resistance thermometer input and Analog
input.
Address
Parameter name Setting (monitor) value LevelFour-
byte
mode
Two-
byte
mode
0C00 2C00 Input Type (TC/Pt multi-
input models) (See note.)
H'00000000 (0): Pt (−200 to 850°C/−300 to 1500°F)
H'00000001 (1): Pt (−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000002 (2): Pt (0.0 to 100.0°C/0.0 to 210.0
°F )
H'00000003 (3): JPt (−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000004 (4): JPt (0.0 to 100.0°C/0.0 to 210.0
°F )
H'00000005 (5): K (−200 to 1300°C/−300 to 2300°F)
H'00000006 (6): K (−20.0 to 500.0°C/0.0 to 900.0°F)
H'00000007 (7): J (−100 to 850°C/−100 to 1500°F)
H'00000008 (8): J (−20.0 to 400.0°C/0.0 to 750.0°F)
H'00000009 (9): T (−200 to 400°C/−300 to 700°F)
H'0000000A (10): T (−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000B (11): E (−200 to 600°C/−300 to 1100°F)
H'0000000C (12): L (−100 to 850°C/−100 to 1500°F)
H'0000000D (13): U (−200 to 400°C/−300 to 700°F)
H'0000000E (14): U (−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000F (15): N (−200 to 1300°C/−300 to 2300°F)
H'00000010 (16): R (0 to 1700°C/0 to 3000°F)
H'00000011 (17): S (0 to 1700°C/0 to 3000°F)
H'00000012 (18): B (100 to 1800°C/300 to 3200°F)
H'00000013 (19): Infrared temperature sensor
(K 140°F/60°C)
H'00000014 (20): Infrared temperature sensor
(K 240°F/120°C)
H'00000015 (21): Infrared temperature sensor
(K 280°F/140°C)
H'00000016 (22): Infrared temperature sensor
(K 440°F/220°C)
H'00000017 (23): 0 to 50 mV
H'00000018 (24): W (0 to 2300°C/0 to 3200°F)
H'00000019 (25): PL II (0 to 1300°C/0 to 2300°F)
Initial
setting
Input Type (Analog input
models, see note)
H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
H'00000002 (2): 1 to 5 V
H'00000003 (3): 0 to 5 V
H'00000004 (4): 0 to 10 V
0C02 2C01 Temperature Unit H'00000000 (0): °C
H'00000001 (1): °F
0C12 2C09 Scaling Lower Limit H’FFFFF831 to scaling upper limit −1
(−1999 to scaling upper limit −1)
0C16 2C0B Scaling Upper Limit Scaling lower limit +1 to H’0000270F
(Scaling lower limit +1 to 9999)
0C18 2C0C Decimal Point (TC/Pt
universal input models)
H'00000000 to 00000001 (0 to 1)
Decimal Point (Analog
input models)
H'00000000 to 00000003 (0 to 3)
0C1E 2C0F PV Decimal Point Display H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
