SECTION 6 Communications Data for Modbus
6-8
Address
Parameter name Setting (monitor) value LevelFour-
byte
mode
Two-
byte
mode
0D06 2D03 Linear Current Output H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
Initial
setting
0D1E 2D0F SP Upper Limit The range of values (without decimal point) is as follows:
Temperature: SP lower limit + 1 to Input range upper limit
Analog: SP lower limit + 1 to scaling upper limit
0D20 2D10 SP Lower Limit The range of values (without decimal point) is as follows:
Temperature: Input range lower limit to SP upper limit − 1
Analog: Scaling lower limit to SP upper limit − 1
0D22 2D11 Standard or Heating/
Cooling
H'00000000 (0): Standard
H'00000001 (1): Heating and cooling
0D24 2D12 Direct/Reverse Opera-
tion
H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
0D28 2D14 PID ON/OFF H'00000000 (0): ON/OFF
H'00000001 (1): 2 PID control
0D2A 2D15 ST H'00000000 (0): OFF
H'00000001 (1): ON
0D2C 2D16 Program Pattern H'00000000 (0): OFF
H'00000001 (1): STOP
H'00000002 (2): CONT
0E00 2E00 Transfer Output Type H'00000000 (0): OFF
H'00000001 (1): Set point
H'00000002 (2): Set point during SP ramp
H'00000003 (3): PV
H'00000004 (4): MV monitor (heating)
H'00000005 (5): MV monitor (cooling)
