SECTION 6 Communications Data for Modbus
6-10
Note 1: For Controllers with two event inputs (events 1 and 2), this cannot be set if the Number of Multi-SP
Uses parameter is set to 1 or 2.
Note 2: For Controllers with two event inputs (events 1 and 2), this cannot be set if the Number of Multi-SP
Uses parameter is set to 2.
Note 3: PRST (program start) can be set even when the program pattern is set to OFF, but the function
will be disabled.
Note 4: The setting (monitor) range depends on the transfer output type setting. (See the setting data list
for details.)
Note 5: P.END (program end output) can be set even when the program pattern is set to OFF, but the
function will be disabled.
Note 6: The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the
Control Output 2 ON/OFF Count Alarm turns ON.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0E14 2E0A Event Input Assign-
ment 1 (See note 1.)
H'00000000 (0): None
H'00000001 (1): RUN/STOP (Cannot be set if the “Number of
multi-SP uses” is set to 1 or 2.)
H'00000002 (2): Auto/manual switch (Cannot be set if the
“Number of multi-SP uses” is set to 1 or 2.)
H'00000003 (3): Program Start (Cannot be set if the “Number
of multi-SP uses” is set to 1 or 2.) (See note 3.)
H'00000004 (4): Direct/reverse operation
H'00000005 (5): None
H'00000006 (6): 100% AT execute/cancel
H'00000007 (7): 40% AT execute/cancel
H'00000008 (8): Setting change enable/disable
H'00000009 (9): Communications writing enable/disable
H'0000000A (10): Alarm latch cancel
Advanced
function
setting
0E16 2E0B Event Input Assign-
ment 2 (See note 2.)
H’00000000 to H’0000000A (0 to 10)
* Same as for Event Input Assignment 1.
0E18 2E0C Event Input Assign-
ment 3
H’00000000 to H’0000000A (0 to 10)
* Same as for Event Input Assignment 1.
0E1A 2E0D Event Input Assign-
ment 4
H’00000000 to H’0000000A (0 to 10)
* Same as for Event Input Assignment 1.
0E20 2E10 Auxiliary Output 1
Assignment
H'00000000 (0): None
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output (See note 5.)
H'00000007 (7): Control output ON/OFF count alarm (See note
6.)
0E22 2E11 Auxiliary Output 2
Assignment
H’00000000 to H’00000007 (0 to 7) (Same settings as the Aux-
iliary Output 1 Assignment)
0E24 2E12 Auxiliary Output 3
Assignment
H’00000000 to H’00000007 (0 to 7) (Same settings as the Aux-
iliary Output 1 Assignment)
0E28 2E14 Transfer Output Upper
Limit
H'FFFFF831 to H'0000270F (−1999 to 9999) (See note 4.) Initial set-
ting
0E2A 2E15 Transfer Output Lower
Limit
H'FFFFF831 to H'0000270F (−1999 to 9999) (See note 4.)
