Omron E5AN - Page 113

Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-11
Note: Not displayed on the Controller display when Alarm 3 is not assigned to the output.
Address
Parameter name Setting (monitor) value Level
Four-
byte
mode
Two-
byte
mode
0E48 2E24 Extraction of Square
Root Enable
H'00000000 (0): OFF
H'00000001 (1): ON
Initial set-
ting
0F00 2F00 Alarm 1 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower-limit alarm
H'00000002 (2): Upper-limit alarm
H'00000003 (3): Lower-limit alarm
H'00000004 (4): Upper and lower-limit range alarm
H'00000005 (5): Upper and lower-limit alarm with standby
sequence
H'00000006 (6): Upper-limit alarm with standby sequence
H'00000007 (7): Lower-limit alarm with standby sequence
H'00000008 (8): Absolute-value upper-limit alarm
H'00000009 (9): Absolute-value lower-limit alarm
H'0000000A (10): Absolute-value upper-limit alarm with standby
sequence
H'0000000B (11): Absolute-value lower-limit alarm with standby
sequence
H'0000000C (12): LBA (Loop Burnout Alarm)
H'0000000D (13): PV change rate alarm
0F02 2F01 Alarm 1 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F04 2F02 Alarm 1 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
Initial set-
ting
0F06 2F03 Alarm 2 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower-limit alarm
H'00000002 (2): Upper-limit alarm
H'00000003 (3): Lower-limit alarm
H'00000004 (4): Upper and lower-limit range alarm
H'00000005 (5): Upper and lower-limit alarm with standby
sequence
H'00000006 (6): Upper-limit alarm with standby sequence
H'00000007 (7): Lower-limit alarm with standby sequence
H'00000008 (8): Absolute-value upper-limit alarm
H'00000009 (9): Absolute-value lower-limit alarm
H'0000000A (10): Absolute-value upper-limit alarm with standby
sequence
H'0000000B (11): Absolute-value lower-limit alarm with standby
sequence
H'0000000C (12): No alarm function
H'0000000D (13): PV change rate alarm
0F08 2F04 Alarm 2 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F0A 2F05 Alarm 2 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
Initial set-
ting
0F0C 2F06 Alarm 3 Type (See
note.)
Same settings as the alarm 2 type.
0F0E 2F07 Alarm 3 Latch (See
note.)
H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F10 2F08 Alarm 3 Hysteresis
(See note.)
H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
Initial set-
ting
0F18 2F0C Standby Sequence
Reset
H'00000000 (0): Condition A
H'00000001 (1): Condition B
Advanced
function
setting
0F1A 2F0D Auxiliary Output 1
Open in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F1C 2F0E Auxiliary Output 2
Open in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F1E 2F0F Auxiliary Output 3
Open in Alarm (See
note.)
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
