Omron E5AN Communications Manual

Com Data for CompoWay/F
3.1 Variable Area (Setting Range) List
3-3
Note: The alarm function can also be used in Controllers without alarm output terminals. In this case,
confirm alarm occurrences via the status data.
Note 1: Not displayed on the Controller display when Alarm 3 is not assigned to an output.
Variable
type
Ad-
dress
Parameter name Setting (monitor) value Level
C1 (81) 0000 Operation/Adjustment Pro-
tect
H'00000000 (0): No restrictions in operation and adjust-
ment levels
H'00000001 (1): Move to adjustment level is prohibited.
H'00000002 (2): Display and change of only “PV” and
“PV/SP” parameters is allowed.
H'00000003 (3): Display of only “PV” and “PV/SP” parame-
ters is allowed.
Protect
C1 (81) 0001 Initial Setting/Communica-
tions Protect
H'00000000 (0): Move to initial setting/communications
setting level is allowed. (Move to
advanced function setting level is dis-
played.)
H'00000001 (1): Move to initial setting/communications
setting level is allowed. (Move to
advanced function setting level is not dis-
played.)
H'00000002 (2): Move to initial setting/communications
setting level is prohibited.
C1 (81) 0002 Setting Change Protect H'00000000 (0): OFF (Changing of setup on Controller dis-
play is allowed.)
H'00000001 (1): ON (Changing of setup on Controller dis-
play is prohibited.)
C1 (81) 0003 Set Point SP lower limit to SP upper limit Operation
C1 (81) 0004 Alarm Value 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0005 Alarm Value Upper Limit 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0006 Alarm Value Lower Limit 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0007 Alarm Value 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0008 Alarm Value Upper Limit 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0009 Alarm Value Lower Limit 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000A Alarm Value 3 (See note 1.) H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000B Alarm Value Upper Limit 3
(See note 1.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000C Alarm Value Lower Limit 3
(See note 1.)
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000D Heater Burnout Detection 1 H'00000000 to H'000001F4 (0.0 to 50.0) Adjustment
C1 (81) 000E SP 0 SP lower limit to SP upper limit
C1 (81) 000F SP 1 SP lower limit to SP upper limit
C1 (81) 0010 SP 2 SP lower limit to SP upper limit
C1 (81) 0011 SP 3 SP lower limit to SP upper limit
C1 (81) 0012 Temperature Input Shift H'FFFFF831 to H'0000270F (−199.9 to 999.9)
C1 (81) 0013 Upper Limit Temperature
Input Shift Value
H'FFFFF831 to H'0000270F (−199.9 to 999.9)
C1 (81) 0014 Lower Limit Temperature
Input Shift Value
H'FFFFF831 to H'0000270F (−199.9 to 999.9)
