Omron E5AN Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-4
Variable
type
Ad-
dress
Parameter name Setting (monitor) value Level
C1 (81) 0015 Proportional Band H'00000001 to H'0000270F (0.1 to 999.9) Adjustment
C1 (81) 0016 Integral Time H'00000000 to H'00000F9F (0 to 3999)
C1 (81) 0017 Derivative Time H’00000000 to H’00000F9F (0 to 3999)
(Range when RT is “OFF”)
H’00000000 to H’0000270F (0.0 to 999.9)
(Range when RT is “ON”)
C1 (81) 0018 Cooling Coefficient H'00000001 to H'0000270F (0.01 to 99.99)
C1 (81) 0019 Dead Band H'FFFFF831 to H'0000270F
(−199.9 to 999.9 for TC/Pt universal input models)
(−19.99 to 99.99 for Analog input models)
C1 (81) 001A Manual Reset Value H'00000000 to H'000003E8 (0.0 to 100.0)
C1 (81) 001B Hysteresis (Heating) H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
C1 (81) 001C Hysteresis (Cooling) H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
C1 (81) 001D Heater Burnout Detection 2 H'00000000 to H'000001F4 (0.0 to 50.0)
C1 (81) 001E HS Alarm 1 H'00000000 to H'000001F4 (0.0 to 50.0)
C1 (81) 001F HS Alarm 2 H'00000000 to H'000001F4 (0.0 to 50.0)
C1 (81) 0020 Soak Time H'00000001 to H'0000270F (1 to 9999)
C1 (81) 0021 Wait Band H'00000000 (0): OFF
H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
C1 (81) 0022 MV at Stop Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A
(−105.0 to 105.0)
C1 (81) 0023 MV at PV Error Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A
(−105.0 to 105.0)
C1 (81) 0024 Manual MV Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'FFFFFBE6 to H'0000041A (−105.0
to 105.0)
Manual
Control
C1 (81) 0025 SP Ramp Set Value H'00000000 (0): OFF
H'00000001 to H'0000270F (1 to 9999)
Adjustment
C1 (81) 0026 MV Upper Limit Standard: MV lower limit + 0.1 to H’0000041A (MV lower
limit + 0.1 to 105.0)
Heating and cooling: H'00000000 to H'0000041A (0.0 to
105.0)
C1 (81) 0027 MV Lower Limit Standard: H’FFFFFFCE to MV upper limit − 0.1 (−5.0 to MV
upper limit − 0.1)
Heating and cooling: H'FFFFFBE6 to H'00000000 (−105.0
to 0.0)
