Omron E5AN Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-6
Note: The input type can be selected to match the connected sensor.
There are two input type specifications: Thermocouple/Resistance thermometer input and Analog
input.
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
C3 (83) 0000 Input Type (analog input
models) (See note.)
H
' 00000000 (0): 4 to 20 mA
H
' 00000001 (1): 0 to 20 mA
H
' 00000002 (2): 1 to 5 V
H
' 00000003 (3): 0 to 5 V
H
' 00000004 (4): 0 to 10 V
Initial set-
ting
C3 (83) 0001 Scaling Upper Limit Scaling lower limit + 1 to H’0000270F (scaling lower limit + 1 to
9,999)
0002 Scaling Lower Limit H’FFFFF831 to Scaling upper limit − 1 (−1999 to Scaling upper limit
− 1)
0003 Decimal Point (TC/Pt
universal input models)
H'00000000 to 00000001 (0 to 1)
Decimal Point (analog
input models)
H'00000000 to 00000003 (0 to 3)
0004 Temperature Unit H'00000000 (0): °C
H'00000001 (1): °F
C3 (83)
C3 (83) 0005 SP Upper Limit The range of values (without decimal point) is as follows:
Temperature: SP lower limit + 1 to Input range upper limit
Analog: SP lower limit + 1 to Scaling upper limit
C3 (83) 0006 SP Lower Limit The range of values (without decimal point) is as follows:
Temperature: Input range lower limit to SP upper limit − 1
Analog: Scaling lower limit to SP upper limit − 1
C3 (83) 0007 PID ON/OFF H'00000000 (0): ON/OFF
H'00000001 (1): 2 PID control
C3 (83) 0008 Standard or Heat-
ing/Cooling
H'00000000 (0): Standard
H'00000001 (1): Heating and cooling
C3 (83) 0009 ST H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 000A Control Period (Heating) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
C3 (83) 000B Control Period (Cooling) H'00000000 (0): 0.5
H'00000001 to H'00000063 (1 to 99)
C3 (83) 000C Direct/Reverse Opera-
tion
H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
