Omron E5AN Communications Manual

Com Data for CompoWay/F
3.1 Variable Area (Setting Range) List
3-13
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
C3 (83) 006C Extraction of Square
Root Enable
H'00000000 (0): OFF
H'00000001 (1): ON
Initial set-
ting
C3 (83) 006D PF Setting H'00000000 (0): Not assigned.
H'00000001 (1): Run
H'00000002 (2): Stop
H'00000003 (3): RUN/STOP
H'00000004 (4): 100% AT execute
H'00000005 (5): 40% AT execute
H'00000006 (6): Alarm latch cancel
H'00000007 (7): Auto/manual switch
H'00000008 (8): Monitor/setting item
Advanced
function
setting
C3 (83) 006E Monitor/Setting Item 1 H'00000000 (0): Disabled
H'00000001 (1): PV/SP/Multi-SP
H'00000002 (2): PV/SP/MV
H'00000003 (3): PV/SP/soak time remain
H'00000004 (4): Proportional band (P)
H'00000005 (5): Integral time (I)
H'00000006 (6): Derivative time (D)
H'00000007 (7): Alarm value 1
H'00000008 (8): Alarm value upper limit 1
H'00000009 (9): Alarm value lower limit 1
H'0000000A (10): Alarm value 2
H'0000000B (11): Alarm value upper limit 2
H'0000000C (12): Alarm value lower limit 2
H'0000000D (13): Alarm value 3
H'0000000E (14): Alarm value upper limit 3
H'0000000F (15): Alarm value lower limit 3
C3 (83) 006F Monitor/Setting Item 2 H'00000000 to H'0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
C3 (83) 0070 Monitor/Setting Item 3 H'00000000 to H'0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
C3 (83) 0071 Monitor/Setting Item 4 H'00000000 to H'0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
C3 (83) 0072 Monitor/Setting Item 5 H'00000000 to H'0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
C3 (83) 0073 PV/SP Display Screen
Selection
H'00000000 (0): PV/SP
H'00000001 (1): PV/SP/Multi-SP
PV/SP/MV
H'00000002 (2): PV/SP/MV
PV/SP/Multi-SP
H'00000003 (3): PV/SP/Multi-SP
H'00000004 (4): PV/SP/MV
H'00000005 (5): PV/SP/Multi-SP
PV/SP/Soak Time Remain
H'00000006 (6): PV/SP/MV
PV/SP/Soak Time Remain
H'00000007 (7): PV/SP/Soak Time Remain
C3 (83) 0074 MV Display Selection H'00000000 (0): MV (heating)
H'00000001 (1): MV (cooling)
C3 (83) 0075 PV Decimal Point Dis-
play
H'00000000 (0): OFF
H'00000001 (1): ON
