Com Data for
CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-14
C3 (83) 0076 PV Status Display Func-
tion
H'00000000 (0): OFF
H'00000001 (1): Manual
H'00000002 (2): Stop
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 1 to 3 OR status
H'00000007 (7): Heater alarm
Advanced
function
setting
C3 (83) 0077 SV Status Display Func-
tion
H'00000000 to H'00000006 (0 to 7)
* Same as for PV Status Display Function
C3 (83) 0078 Control Output 1
ON/OFF Count Alarm
Set Value
H'00000000 to H'0000270F (0 to 9999)
C3 (83) 0079 Control Output 2
ON/OFF Count Alarm
Set Value
H'00000000 to H'0000270F (0 to 9999)
C3 (83) 0083 Display Refresh Period H'00000000 (0): OFF
H'00000001 (1): 0.25
H'00000002 (2): 0.5
H'00000003 (3): 1.0
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
