E5CC/E5CC-B/E5CC-U
21
Model Number Legend
Plug-in Models
E5CC-@@ @ @ U M -000 (Example: E5CC-RW0AUM-000)
ABCDEF
* The control output can be used as a simple transfer output for the Digital Temperature Controllers manufactured in May 2014 or later.
List of Models
Heating and Cooling Control
Using Heating and Cooling Control
A Control Output Assignment
An auxiliary output is used as the cooling control output.
B Control
If PID control is used, you can set PID control separately for heating and cooling.
This allows you to handle control systems with different heating and cooling response characteristics.
Model
A B C D E F
Meaning
Control
outputs
1 and 2
No. of
auxiliary
outputs
Power
supply
voltage
Terminal
type
Input
type
Options
E5CC 48 × 48 mm
Control output 1 Control output 2
RW Relay output (SPDT) None
QX Voltage output (for driving SSR) None
CX Linear current output * None
0 None
1 1
2 2 (one common)
A 100 to 240 VAC
D 24 VAC/DC
U Plug-in model
M Universal input
HB alarm and HS
alarm
Communi-
cations
Event inputs
Remote SP
Input
Transfer
output
000 --- --- --- --- ---
Control output
No. of auxiliary
outputs
Options Model Model
HB alarm and
HS alarm
No. of event
inputs
Communications
Power supply voltage Power supply voltage
100 to 240 VAC 24 VAC/DC
Relay output
---
--- --- ---
E5CC-RW0AUM-000 E5CC-RW0DUM-000
1 E5CC-RW1AUM-000 E5CC-RW1DUM-000
2 E5CC-RW2AUM-000 E5CC-RW2DUM-000
Voltage output
(for driving SSR)
---
--- --- ---
E5CC-QX0AUM-000 E5CC-QX0DUM-000
1 E5CC-QX1AUM-000 E5CC-QX1DUM-000
2 E5CC-QX2AUM-000 E5CC-QX2DUM-000
Linear current
output
---
--- --- ---
E5CC-CX0AUM-000 E5CC-CX0DUM-000
1 E5CC-CX1AUM-000 E5CC-CX1DUM-000
2 E5CC-CX2AUM-000 E5CC-CX2DUM-000
