Omron E5CWL Connections

E5CSL/E5CWL/E5EWL
2
Ordering Information
E5CSL
E5CWL
E5EWL
Accessories (Order Separately)
Terminal Cover
Front Panel (for E5CSL/E5CWL)
Note: 1. This Front Panel accessory is required to attach the Y92A-
48B or Y92A-48D.
2. This Front Panel accessory is only the frame.
It does not include the plastic cover.
Adapter
Specifications
Ratings
Note: E5CWL/E5EWL only
Size Power supply voltage Input type Alarm output Control output Model
1/16 DIN
48 48 60
(W H D)
100 to 240 VAC
Thermocouple
None
Relay output
E5CSL-RTC
Resistance thermometer E5CSL-RP
Thermocouple
Voltage output
(for driving SSR)
E5CSL-QTC
Resistance thermometer E5CSL-QP
Size Power supply voltage Input type Alarm output Control output New model
1/16 DIN
48 48 60
(W H D)
100 to 240 VAC
Thermocouple
1
Relay output
E5CWL-R1TC
Resistance thermometer E5CWL-R1P
Thermocouple
Voltage output
(for driving SSR)
E5CWL-Q1TC
Resistance thermometer E5CWL-Q1P
Size Power supply voltage Input type Alarm output Control output New model
1/8 DIN
48 96 60
(W H D)
100 to 240 VAC
Thermocouple
1
Relay output
E5EWL-R1TC
Resistance thermometer E5EWL-R1P
Thermocouple
Voltage output
(for driving SSR)
E5EWL-Q1TC
Resistance thermometer E5EWL-Q1P
Model E53-COV19
Model E53-COV20
Model Remarks
Y92F-45
 Use this Adapter when the Front Panel has
already been prepared for the E5B@.
 Only black is available.
 Order separately.
Y92F-49
 Use for E5CSL/E5CWL only.
 Provided with E5CSL/E5CWL.
Y92F-51
 Use for E5EWL only.
 Provided with E5EWL.
Power supply voltage 100 to 240 VAC, 50/60 Hz
Operating voltage range 85% to 110% of rated supply voltage
Power consumption 3.5 VA
Sensor input
Models with thermocouple inputs
Thermocouple: K, J, T, R, or S
Models with platinum resistance thermometer inputs
Platinum resistance thermometer: Pt100
Control
output
Relay output SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations, minimum load: 5 V, 10 mA
Voltage output
(for driving
SSR)
Output voltage: 12 VDC 25%/15% (PNP), max. load current: 21 mA, with short-circuit protection circuit
Alarm output (See note.) SPST-NO, 250 VAC, 1 A (resistive load), electrical life: 100,000 operations, minimum load: 5 V, 10 mA
Control method ON/OFF control or 2-PID control (with auto-tuning)
Setting method Digital setting using front panel keys
Indication method
7-segment digital display and individual indicators
Character height: E5CSL: 21.7 mm, E5CWL: 16.2 mm (PV), E5EWL: 20 mm (PV)
Other functions Temperature input shift, run/stop, protection functions, etc.
Ambient operating
temperature
10 to 55C (with no icing or condensation)
Ambient operating humidity 25% to 85%
Storage temperature 25 to 65C (with no icing or condensation)
Downloaded from Arrow.com.Downloaded from Arrow.com.

Omron E5CWL Specifications

General

Brand	Omron
Model	E5CWL
Category	Temperature Controller
Language	English
