2 Digital Temperature Controllers E5AZ
Digital Temperature Controllers
E5AZ
Next-generation Digital Temperature
Controller
• Depth of only 78 mm.
• Various temperature inputs: thermocouple, platinum resistance
thermometer, infrared temperature sensor, and analog inputs.
• Auto-tuning and self-tuning are available. Auto-tuning is possi-
ble even while self-tuning is being executed.
• Heating or heating/cooling control is available.
• Event input allows multi-SP selection and run/stop function.
• Modular output cards.
• Time delay alarm function.
• Communications function.
• CE marking and UL/CSA approval.
Refer to the "Safety Precautions" on page 52.
96 × 96 × 78 mm (W × H × D)
®
Model Number Structure
■ Model Number Legend
1. Output type
R: Relay
Q: Voltage (for driving SSR)
C: Current
A: Output Unit can be mounted
2. Number of alarms
3: Three alarms
3. Option 1
Blank: Not available
H: Heater Burnout Alarm
4. Option 2
Blank: Not available
01: RS-232C
02: RS-485
B: 2 event inputs
Note: Options 1 and 2 are supported when using an E53-AZM Option
Board.
123 4
E5AZ- @ 3 @ @

Omron E5CZ Specifications

General

Display Type	7-segment digital display
Dimensions	48 x 48 x 78 mm
Number of Control Outputs	1
Ambient Operating Temperature	-10 to 55°C
Control Method	PID control, ON/OFF control
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Alarm Output	1 or 2 (depending on model)
Setting Resolution	0.1 or 1 (depending on input type)
Protection Rating	IP20
Ambient Operating Humidity	25% to 85% RH (non-condensing)
