E5DC
40
USB-Serial Conversion Cable
Specifications
Windows is a registered trademark of Microsoft Corporation in the United
States and other countries.
* Use a high-power port for the USB port.
Note: A driver must be installed on the computer. Refer to the
Instruction Manual included with the Cable for the installation
procedure.
Communications Specifications
* The baud rate, data bit length, stop bit length, and vertical parity can
be individually set using the Communications Setting Level.
Communications Functions
MELSEC is a registered trademark of Mitsubishi Electric Corporation.
* A Digital Temperature Controller with version 1.0 or higher is required.
Current Transformer (Order Separately)
Ratings
Heater Burnout Alarms and SSR Failure
Alarms
*1 For heater burnout alarms, the heater current will be measured when the
control output is ON, and the output will turn ON if the heater current is
lower than the set value (i.e., heater burnout detection current value).
*2 For SSR failure alarms, the heater current will be measured when the
control output is OFF, and the output will turn ON if the heater current is
higher than the set value (i.e., SSR failure detection current value).
*3 The value is 30 ms for a control period of 0.1 s or 0.2 s.
*4 The value is 35 ms for a control period of 0.1 s or 0.2 s.
Electrical Life Expectancy Curve for
Control Output Relay (Reference Values)
Applicable OS Windows 2000, XP, Vista, or 7
Applicable software
CX-Thermo version 4.6 or higher
Applicable models E5@C Series and E5CB Series
USB interface stan-
dard
Conforms to USB Specification 2.0
DTE speed 38,400 bps
Connector
specifications
Computer: USB (Type A plug)
Digital Temperature Controller: Special serial con-
nector
Power supply Bus power (supplied from the USB host controller) *
Power supply voltage 5 VDC
Current consumption 450 mA max.
Output voltage
4.7±0.2 VDC (Supplied from USB-Serial Conver-
sion Cable to the Digital Temperature Controller.)
Output current
250 mA max. (Supplied from USB-Serial Conver-
sion Cable to the Digital Temperature Controller.)
Ambient operating
temperature
0 to 55°C (with no condensation or icing)
Ambient operating
humidity
10% to 80%
Storage temperature
20 to 60
°
C (with no condensation or icing)
Storage humidity 10% to 80%
Altitude 2,000 m max.
Weight Approx. 120 g
Transmission line connection
method
RS-485: Multidrop
Communications RS-485 (two-wire, half-duplex)
Synchronization method Start-stop synchronization
Protocol CompoWay/F or Modbus
Baud rate 9,600, 19,200, 38,400, or 57,600 bps
Transmission code ASCII
Data bit length * 7 or 8 bits
Stop bit length * 1 or 2 bits
Error detection
Vertical parity (none, even, or odd)
Block check character (BCC)
with CompoWay/F or
CRC-16 with Modbus
Flow control None
Interface
RS-485
Retry function None
Communications buffer 217 bytes
Communications response
wait time
0 to 99 ms
Default: 20 ms
Programless
communications *
You can use the memory in the PLC to read and write
E5@C parameters, start and stop operation, etc.
The E5@C automatically performs communications
with the PLC. No communications programming is re-
quired.
Number of connected Digital Temperature Controllers:
32 max.
Applicable PLCs: OMRON PLCs
SYSMAC CS Series, CJ Series, or CP Series
Mitsubishi Electric PLCs
MELSEC Q Series or L Series
Communications
between
components *
When Digital Temperature Controllers are connected,
the parameters can be copied from the Digital Temper-
ature Controller that is set as the master to the Digital
Temperature Controllers that are set as slaves.
Number of connected Digital Temperature Controllers:
32 max. (including master)
When Digital Temperature Controllers are connected,
set points and RUN/STOP commands can be sent from
the Digital Temperature Controller that is set as the
master to the Digital Temperature Controllers that are
set as slaves.
Slope and offsets can be set for the set point.
Number of connected Digital Temperature Controllers:
32 max. (including master)
Dielectric strength 1,000 VAC for 1 min
Vibration resistance 50 Hz, 98 m/s
2
Weight
E54-CT1: Approx. 11.5 g,
E54-CT3: Approx. 50 g
Accessories (E54-CT3 only)
Armatures (2)
Plugs (2)
CT input (for heater current
detection)
Models with detection for single-phase heat-
ers: 1 input
Maximum heater current 50 A AC
Input current
indication accuracy
±5% FS ±1 digit max.
Heater burnout alarm
setting range *1
0.1 to 49.9 A (in units of 0.1 A)
Minimum detection ON time: 100 ms *3
SSR failure alarm setting
range *2
0.1 to 49.9 A (in units of 0.1 A)
Minimum detection OFF time: 100 ms *4
500
300
100
50
30
10
5
3
1
0123456
Switching current (A)
E5DC
250 VAC, 30 VDC
(resistive load)
cosφ = 1
Life (× 10
4
operations)
