3 Communications Data for CompoWay/F
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
3
Variable
type
Address Parameter name Setting (monitor) value Level
C1 (81) 0024 Manual MV Standard Models
Standard control:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling control:
H'FFFFFBE6 to H'0000041A (−105.0 to 105.0)
Position-proportional Models
Close position-proportional control with the Direct
Setting of Position Proportional MV parameter set
to ON:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Manual
Control
C1 (81) 0025 SP Ramp Set
Value
H'00000000 (0): OFF
H'00000001 to H'0000270F (1 to 9999)
Adjustment
C1 (81) 0026 MV Upper Limit Standard control or close position-proportional control:
MV lower limit + 0.1 to H'0000041A
(MV lower limit + 0.1 to 105.0)
Heating and cooling control:
H'00000000 to H'0000041A (0.0 to 105.0)
C1 (81) 0027 MV Lower Limit Standard control or close position-proportional control:
H'FFFFFFCE to MV upper limit − 0.1
(−5.0 to MV upper limit − 0.1)
Heating and cooling control:
H'FFFFFBE6 to H'00000000 (−105.0 to 0.0)
C1 (81) 0028 Move to Protect
Level
H'FFFFF831 to H'0000270F (-−1999 to 9999) Protect
C1 (81) 0029 Password to Move
to Protect Level
H'FFFFF831 to H'0000270F (−1999 to 9999)
(Can only be set. The monitor value is always
H'00000000.)
C1 (81) 002A Parameter Mask
Enable
H'00000000 (0): OFF
H'00000001 (1): ON
C1 (81) 002B PF Key Protect H'00000000 (0): OFF
H'00000001 (1): ON
