E5DC/E5DC-B
75
Mounting Adapters
Y92F-53 (Two included.)
Short Bars
Y92S-P11 (Four included.)
End Plate
PFP-M
DIN Tracks
PFP-100N
PFP-50N
Spacer
PFP-S
Unit Labels
Y92S-L2
End Cover
Y92F-54 (Two included.)
12
34.7
11.8
9.4
This accessory is not included with the
product. Order it separately to mount
the product to a panel.
3
2.4
0.8
24.8
27.5
22.5
5
Use this product to connect between terminals (for power supplies,
communications, etc.) when you use multiple E5DC Controllers.
50
11.5
10
M4×8
pan head
screw
M4 spring washer
4.8
1.3
1.8
1
10
6.2
1.8
35.5 35.3
4.5
15 25 25
10 10
1000 (500) *
25 25 15 (5) *
35
±0.3
7.3
±0.15
27
±0.15
1
* Dimensions in parentheses are for the PFP-50N.
5
16
12
44.3
34.8
16.5
The Unit Labels for the Digital Panel
Meter are used. Use either the °C or °F
label from the sheet.
5.3
3.9
68
96
Use the End Cover when you mount the E5DC/E5DC-B to a
panel to hide the gap between the Controller and the panel.
