Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC
Setting Temperature Alarms
4-12
Setting Temperature Alarms
Alarm Latch
You set a latch for an alarm output. If an alarm latch is enabled, the alarm, once it turns ON, will remain
ON regardless of the present temperature until it is cleared by turning OFF the power, pressing the PF
Key, or using an event input.
* For details, refer to the E5CC/E5EC Digital Temperature Controllers User's Manual
(Cat. No. H174).
Press the (Mode)
Key several times to
display
a1lt
(A1LT).
Change between ON
and OFF with the
(Up and Down) Keys.
If required, use the (Mode) Key and the (Up and Down) Keys to repeat steps 2 and 3 and
set ON/OFF for
a2lt
(A2LT) (Alarm 2 Latch),
a3lt
(A3LT) (Alarm 3 Latch), and
a4lt
(A4LT) (Alarm 4
Latch). (The number of alarms that is supported depends on the model of Temperature Controller.
Some of the alarm parameters may not be displayed.)
a1lt (A1LT):
←
Indicates the Alarm 1 Latch parameter.
←Default setting is off (OFF).
Advanced Function
Setting Level
←init (INIT) will be displayed to
show that the Advanced Function
Setting Level has been entered.
Go to the Advanced Function Setting Level.
Change the parameter with the Key.
2
Set the parameter with the Keys.
3
(When finished, press the (Level) Key for at least 1 second to return to the Initial Setting Level.)
Refer to
Moving to the
To Next Page
