Setting the Sensor Type
1-1
Setting the Sensor Type
Setting the Sensor Type
Select and set the sensor type (i.e., the Input Ty pe parameter) to the set value that corresponds to
the type of sensor used in the application and the required temperature range.
The parameter is set to 5 (K thermocouple at −200 to 1,300 °C) by default.
Thermocouples
Resistance
Thermometers
E5CC/E5EC
K
J
T
R. etc.
Pt
JPt
E5CC/E5EC
Input type Sensor type
Input temperature setting
range in °C
Input temperature setting
range in °F
E5CC/E5EC set
value
−200
to 850
°C
−300
to 1500
°F
0
−199.9
to 500.0
°C
−199.9
to 900.0
°F
1
Pt100
0.0 to 100.0
°C
0.0 to 210.0 °F
2
−199.9
to 500.0
°C
−199.9
to 900.0
°F
3
Resistance
thermometer
JPt100
0.0 to 100.0
°C
0.0 to 210.0 °F
4
−200
to 1300
°C
−300
to 2300
°F
5 (default)
K
−20.0
to 500.0
°C
0.0 to 900.0 °F
6
−100
to 850
°C
−100
to 1500
°F
7
J
−20.0
to 400.0
°C
0.0 to 750.0 °F
8
−200
to 400
°C
−300
to 700
°F
9
T
−199.9
to 400.0
°C
−199.9
to 700.0
°F
10
E
−200
to 600
°C
−300
to 1100
°F
11
L
−100
to 850
°C
−100
to 1500
°F
12
−200
to 400
°C
−300
to 700
°F
13
U
−199.9
to 400.0
°C
−199.9
to 700.0
°F
14
N
−200
to 1300
°C
−300
to 2300
°F
15
R 0 to 1700
°C
0 to 3000 °F
16
S 0 to 1700
°C
0 to 3000 °F
17
B 100 to 1800
°C
300 to 3200 °F
18
W 0 to 2300
°C
0 to 3200 °F
19
Thermocouple
PLII 0 to 1300
°C
0 to 2300 °F
20
* When using the ES1B Infrared Temperature Sensor and an analog input, refer to the E5CC/E5EC Digital Temperature
Controllers User's Manual (Cat. No. H174).
←If the setting of the Input Type parameter does not agree with the connected sensor,
s.err (S.ERR: Input Error) will flash on the display as shown at the left when the power
supply is turned ON.
Use the procedure on page 1-2 to set the Input Type parameter correctly.
Any value can be set for any model.
