EJ1
19
Options
Current Transformer (Sold Separately)
40@
30
12 dia.
9
2.36 dia.
15
30
Two, M3 (depth: 4)
E54-CT3
Plug
Armature
Lead
30
21
15
5.8 dia.
25
3
40
10.5
2.8
7.5
10
Two, 3.5 dia.
E54-CT1
Connection Example
Approx. 3 dia.
18
(22)
Approx. 6 dia.
E54-CT3 Accessory
• Armature
• Plug
Rail Mounting Equipment (Order Separately)
DIN Rail
PFP-100N
PFP-50N
* The figures in parentheses are
dimensions for the PFP-50N.
4.5
15 25 25
10 10
1000 (500) *
25 25 15 (5) *
35
±0.3
7.3±0.15
27±0.15
1
50
11.5
10
M4 × 8
panhead
screw
M4 spring washer 4.8
1.3
1.8
1
10
6.2
1.8
35.5 35.3
End Plate
PFP-M
Note: Two screws are included with the EJ1C-EDU for the End Plate.
Always attach End Plates to both sides.
