Omron F3SJ-E P25 Series - Page 23

7
F3SJ-E/B
User’s Manual
Chapter1 Ratings/Specifications
Overview and Specifications
E
*1. The load inductance is the maximum value when the safety output frequently repeats ON and OFF. When you use the safety
output at 4 Hz or less, the usable load inductance becomes larger.
*2. These values must be taken into consideration when connecting elements including a capacitive load such as a capacitor.
*3. The Vs indicates a voltage value in your environment.
Item
Model
Easy Type Basic Type
F3SJ-EP25 F3SJ-BP25
Protection circuit Output short-circuit protection, and power supply reverse polarity protection
Ambient temperature During operation: -10 to 55°C (non-freezing), During storage: -25 to 70°C
Ambient humidity During operation: 35 to 85%RH (non-condensing), During storage: 35 to 95%RH
Ambient light intensity
Incandescent lamp: 3,000 lx max. on receiving surface. Sunlight: 10,000 lx max. on
receiving surface.
Insulation resistance 20 MΩ or higher (500 VDC)
Dielectric strength 1,000 VAC, 50/60 Hz, 1 min
Degree of protection IP65 (IEC 60529)
Vibration resistance
Malfunction: 10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps each in X, Y, and Z
directions
Shock resistance Malfunction: 100 m/s
2
, 1,000 times each in X, Y, and Z directions
Pollution degree Pollution degree 3 (IEC 60664-1)
Power cable
Connection
method
Prewired cable, cable length 3 m
Prewired connector cable, cable length 0.3 m
Connector type (M12, 8-pin)
Connector: IP67 rated (when mated)
Number of wires Emitter: 5 wires, receiver: 6 wires 8 wires
Cable diameter Dia. 6 mm
Allowable
bending radius
R5 mm
Series connection cable
(F39-JBR2W)
Connection
method
–
Prewired connector cable, cable length 0.2 m
Connector type (M12, 8-pin)
Connector: IP67 rated (when mated)
Number of wires 8 wires
Cable diameter Dia. 6 mm
Allowable
bending radius
R5 mm
Extension cable
(F39-JDA, JDB)
Connection
method
Refer to "<Extension cable>" on
page 91.
Connector method (M12, 8-pin)
IP67 degree of protection for connector
(fitting)
For details about twisted pair wires
(single-ended cable) p.88, (double-
ended cable) p.89
For details about total extension
cable length
Number of wires 8 wires
Cable diameter Dia. 6.6 mm
Allowable
bending radius
R36 mm
Extension cable 30 m max.
Material
Case: Aluminum
Cap: ABS resin, PBT
Optical cover: PMMA resin (acrylic)
Cable: Oil resistant PVC
Weight (packaged) F3SJ-EP25
Weight (g) = (protective height) x 2.6 + 800
F3SJ-BP25
Weight (g) = (protective height) x 2.7 + 500
Accessories Quick Installation Manual(QIM), Instruction manual
Applicable standards
Refer to "Legislation and Standards" on page i.
