Chapter1 Ratings/Specifications
F3SJ-E/B
User’s Manual
Overview and Specifications
Ratings/Specifications
The model names of the F3SJ-E/B contain the 4 digits indicating the protective height (mm).
Item
Model
Easy Type Basic Type
F3SJ-EP25 F3SJ-BP25
Detection capability
Opaque objects
25 mm diameter
Beam gap 20 mm
Number of beams 8 to 54 8 to 102
Protective height 185 to 1,105 mm 185 to 2,065 mm
Lens diameter 5 mm
Operating range 0.2 to 7 m
Response time
ON to OFF: 15 ms max. (Response time when used alone or in 2 or 3 connected)
OFF to ON: 70 ms max. (Response time when used alone or in 2 or 3 connected)
Startup waiting time 2 s max.
Power supply voltage (Vs) SELV/PELV 24 VDC±20% (ripple p-p 10% max.)
Current consumption
Refer to "Model/Current Consumption List" on page 9.
Light source Infrared LED (870 nm wavelength)
Effective aperture angle (EAA)
Based on IEC 61496-2.
Within ±2.5° for both emitter and receiver at an operating range of 3 meters or more.
Safety output (OSSD)
Two PNP transistor outputs, Load current: 200 mA max., Residual voltage: 2 V max.
(except for voltage drop due to cable extension), Leakage current: 1 mA max., Load
inductance: 2.2 H max. *1
Maximum capacitive load: 1 µF *2
Auxiliary output –
One PNP transistor output
Load current: 100 mA max.
Residual voltage: 2 V max.(except for voltage
drop due to cable extension)
Leakage current: 1 mA max.
Output operation mode Safety output: ON when receiving light
Safety output: On when receiving light
Auxiliary output:
- Basic system
Reverse output of safety output
- Muting system
ON during muting/override
Input voltage
Test input:
ON voltage: Vs-3 V to Vs *3 (short circuit current:
approx. 3.0 mA)
OFF voltage: 0 V to 1/2 Vs, or open *3 (short circuit
current: approx. 4.0 mA)
Test input, Interlock select input, Reset input,
Muting input:
ON voltage: Vs-3 V to Vs *3 (short circuit current:
approx. 3.0 mA)
OFF voltage: 0 V to 1/2 Vs, or open *3(short circuit
current: approx. 4.0 mA)
External device monitoring input:
ON voltage: Vs-3 V to Vs *3 ((short circuit current:
approx. 6.0 mA))
OFF voltage: open
Overvoltage category II (IEC 60664-1)
Indicator
Refer to "Internal (LED) Indicator Display Pattern" on page 4.
Mutual interference prevention function Mutual interference prevention algorithm prevents interference in up to three sets.
Series connection function –
Number of connections: Up to three sets
Total number of beams: Up to 192
Maximum connection cable length: 7 m
(connection cable (F39-JBR2W) and
F3SJ's cable are not included)
Test function
Self-test (at power-on, and during operation)
External test (light emission stop function by test input)
Safety-related functions –
Interlock (basic system)
External device monitoring (basic system)
Muting (muting system)
Override (muting system)
