Camera Cable for FZ-S Camera Series
Name Model Length
Digital CCD Camera (Standalone)
0.3 megapixel
camera
2 megapixel cam-
era
5 megapixel cam-
era
FZ-S/SC FZ-S2M/SC2M FZ-S5M3/SC5M3
Camera cable
Right-angle Camera ca-
ble
FZ-VS3
FZ-
VSL3
2 m OK OK OK
3 m OK OK OK
5 m OK OK OK
10 m OK OK -
Bend resistant Camera
cable
Bend resistant Right-an-
gle Camera cable
FZ-
VSB3
FZ-
VSLB3
2 m OK OK OK
3 m OK OK OK
5 m OK OK OK
10 m OK OK -
Long-distance Camera
cable
Long-distance Right-an-
gle Camera cable
FZ-VS4
FZ-
VSL4
15 m OK OK -
Name Model Length
Small Digital CCD
Camera (Stand-
alone)
Flat type/pen type
High-speed digital
CCD Camera
(Standalone)
Intelligent Com-
pact Digital CMOS
Camera
FZ-SF/SFC
FZ-SP/SPC
FZ-SH/SHC
FZ-SQ£
Camera cable
Right-angle Camera ca-
ble
FZ-VS3
FZ-
VSL3
2 m OK OK OK
3 m OK OK OK
5 m OK OK OK
10 m OK OK OK
Bend resistant Camera
cable
Bend resistant Right-an-
gle Camera cable
FZ-
VSB3
FZ-
VSLB3
2 m OK OK OK
3 m OK OK OK
5 m OK OK OK
10 m OK OK OK
Long-distance Camera
cable
Long-distance Right-an-
gle Camera cable
FZ-VS4
FZ-
VSL4
15 m OK OK OK
