Item Model
Trans-
mis-
sion
speed
*1
No. of
CH
used
for
con-
nec-
tion
*2
Maximum
cable
length us-
ing 1 Cam-
era Cable
*1
Max.
num-
ber of
con-
necta-
ble
Exten-
sion
Units
Using Cable Extension Units
FZ-VSJ
Max.
cable
length
Connection config-
uration
Digital CMOS
Cameras
FH-SM21R/
SC21R
Stand-
ard
1CH 5 m (Using
FZ-VS4/
VSL4)
2 45 m [Configuration 1]
Camera cable: 15 m
x 3
Extension Unit: 2
2CH 15 m (Us-
ing FZ-VS4/
VSL4)
4
*3
45 m [Configuration 2]
Camera cable: 15 m
x 6
Extension Unit: 4
High
speed
1CH 5 m (Using
FZ-VS
£/VSL£)
2 15 m [Configuration 3]
Camera cable: 15 m
x 3
Extension unit: 2
2CH 5 m (Using
FZ-VS
£/VSL£)
4
*3
15 m [Configuration 4]
Camera cable: 5 m x
6
Extension Unit: 4
FH-SM05R/
SC05R
- - 15 m (Us-
ing FZ-VS4/
VSL4)
2 45 m [Configuration 1]
Camera cable: 15 m
x 3
Extension Unit: 2
FZ-S5M3/
SC5M3
- - 5 m (Using
FZ-VS
£/VSL£)
2 15 m [Configuration 3]
Camera cable: 15 m
x 3
Extension unit: 2
Digital CCD/
CMOS Cameras
FZ-S/SC
FZ-S2M/SC2M
- - 15 m (Us-
ing FZ-VS4/
VSL4)
2 45 m [Configuration 1]
Camera cable: 15 m
x 3
Extension Unit: 2
Small Digital
CCD Cameras
Flat type/pen
type
FZ-SF/SFC
FZ-SP/SPC
- - 15 m (Us-
ing FZ-VS4/
VSL4)
2 45 m [Configuration 1]
Camera cable: 15 m
x 3
Extension Unit: 2
High-speed digi-
tal CCD Cam-
eras
FZ-SH/SHC - - 15 m (Us-
ing FZ-VS4/
VSL4)
2 45 m [Configuration 1]
Camera cable: 15 m
x 3
Extension Unit: 2
Intelligent Com-
pact Digital
CMOS Cameras
FZ-SQ£
- - 15 m (Us-
ing FZ-VS4/
VSL4)
2 45 m [Configuration 1]
Camera cable: 15 m
x 3
Extension Unit: 2
*1.
The FH-S£££enables switching between standard and high speed modes. In high speed mode, images
can be transferred approximately two times faster than in standard mode, but the connectable cable length
will be shorter
.
