Model
3Z4S-LE VS-MCA25-££££
*1
Optical magnifica-
tion
0.05x 0.25x 0.50x
Aperture (fixed F
No.)
2 5.6 8 2 5.6 8 2 5.6 8
Depth of field
(mm)
*2
67.2 188.8 268.8 3.2 9.0 12.8 1.0 2.7 3.8
Maximum sensor
size
2/3 inch
Mount C mount
Model
3Z4S-LE VS-MCA30-££££
*1
Appearance/
Dimensions
(Unit: mm)
24.5 [0.06x] to 36.2 [0.45x]
31 dia.
Focal length (mm) 30
Filter size M27.0 P0.5
Optical magnifica-
tion
0.06x 0.15x 0.45x
Aperture (fixed F
No.)
2 5.6 8 2 5.6 8 2 5.6 8
Depth of field
(mm)
*2
53.3 131.1 188.9 8.2 22.8 32.7 1.3 3.2 4.6
Maximum sensor
size
2/3 inch
Mount C mount
Model
3Z4S-LE VS-MCA35-££££
*1
Appearance/
Dimensions
(Unit: mm)
32.0 [0.26x] to 45.7 [0.65x]
31 dia.
Focal length (mm) 35
Filter size M27.0 P0.5
Optical magnifica-
tion
0.26x 0.30x 0.65x
Aperture (fixed F
No.)
2 5.6 8 2 5.6 8 2 5.6 8
Depth of field
(mm)
*2
3.0 8.4 12.0 2.2 6.5 9.2 0.7 1.7 2.5
Maximum sensor
size
2/3 inch
Mount C mount
3 Configuration
