l
XW2Z-S013-£
Unfused part
Cable mark
L
*1
1
2
33
34
(70) (70) (15)(30)
Fused part
*1. Cable is available in 2 m/5 m.
Pin Layout
No. I/O
XW2Z-S013-£
W
ire color
XW2R-£34GD-
T Connector-
Terminal Block
Conversion
Units, General-
purpose devi-
ces
Signal name
CN1
1 - Red A1 COMIN0
2 - Gray B1 COMIN1
3 - Gray A2 Vacant
4 IN Gray B2 STEP0
5 IN Green A3 Vacant
6 IN Gray B3 Vacant
7 IN Gray A4 Vacant
8 IN Gray B4 Vacant
9 IN Gray A5 Vacant
10 IN Green B5 Vacant
11 IN Gray A6 Vacant
12 IN Gray B6 Vacant
13 IN Gray A7 Vacant
14 IN Gray B7 Vacant
15 OUT Green A8 RUN0
16 OUT Gray B8 READY0
17 OUT Gray A9 BUSY0
6 I/O Interface
6-15
FH Series Vision System Hardware Setup Manual (Z366-E1)
6-1 Parallel Interface
6
6-1-3 FH-L Series
