FQ2
8
Touch Finder
*1 This is a guideline for the time required for the brightness to diminish to half the initial brightness at room temperature and humidity. The life of the backlight is
greatly affected by the ambient temperature and humidity and will be shorter at lower or higher temperatures.
*2 This value is only a guideline. No guarantee is implied. The value will be affected by operating conditions.
*3 This value is only a guideline. No guarantee is implied. The value will be affected by the operating environment and operating conditions.
Sensor Data Units (FQ2-S3/S4 only)
Type
Item Model
Model with DC power supply Model with AC/DC/battery power supply
FQ2-D30 FQ2-D31
Number of connectable Sensor
Number of sensors that can be recognized (switched): 32 max. number or sensor that can displayed on
monitor: 8 max.
Main functions
Types of measurement displays Last result display, Last NG display, trend monitor, histograms
Types of display images Through, frozen, zoom-in, and zoom-out images
Data logging Measurement results, measured images
Menu language English, German, French, Italian, Spanish, Traditional Chinese, Simplified Chinese, Korean, Japanese
Indications
LCD
Display device 3.5-inch TFT color LCD
Pixels 320 240
Display colors 16.7 million
Backlight
Life expectancy *1 50,000 hours at 25ºC
Brightness adjustment Provided
Screen saver Provided
Operation
interface
Touch
screen
Method Resistance film
Life expectancy *2 1,000,000 touch operations
External
interface
Ethernet 100BASE-TX/10BASE-T
SD card
SDHC-compliant, Class 4 or higher recommended
Ratings
Power supply voltage
DC power connection:21.6 to 26.4 VDC
(including ripple)
DC power connection: 21.6 to 26.4 VDC
(including ripple)
AC adapter (manufactured by Sino-American Japan
Co., Ltd) connection: 100 to 240 VAC, 50/60 Hz
Battery connection: FQ-BAT1 Battery (1cell, 3.7 V)
Continuous operation on Battery *3 --- 1.5 h
Power consumption DC power connection: 0.2 A max.
DC power connection: 0.2 A max.
Charging battery: 0.4 A max.
Environmental
immunity
Ambient temperature range
Operating: 0 to 50ºC
Storage: 25 to 65ºC
(with no icing or condensation)
Operating:
0 to 50ºC when mounted to DIN Track or panel
Operation on Battery: 0 to 40ºC
Storage: 25 to 65ºC
(with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Ambient atmosphere No corrosive gas
Vibration resistance (destruction)
10 to 150 Hz, single amplitude: 0.35 mm, X/Y/Z directions
8 min each, 10 times
Shock resistance (destruction) 150 m/s
2
3 times each in 6 direction (up, down, right, left, forward, and backward)
Degree of protection IEC 60529 IP20 (when SD card cover, connector cap, or harness is attached)
Weight Approx. 270 g (without Battery and hand strap attached)
Materials Case: ABS
Accessories included with Touch Finder Touch Pen (FQ-XT), Instruction Manual
Item Parallel Interface RS-232C Interface
Model
NPN FQ-SDU10 FQ-SDU20
PNP FQ-SDU15 FQ-SDU25
I/O
specifications
Parallel I/O
Connector 1 16 outputs (D0 to D15) 6 inputs (IN0 to IN5)
Connector 2
11 inputs (TRIG, RESET, IN0 to IN7, and DSA)
8 outputs (GATE, ACK, RUN, BUSY, OR, ERROR,
STGOUT, and SHTOUT)
2 inputs (TRIG and RESET)
7 outputs (ACK, RUN, BUSY, OR, ERROR,
STGOUT, and SHTOUT)
RS-232C --- 1 channel, 115,200 bps max.
Sensor interface
FQ2-S3 connected with FQ-WU@@@ : OMRON interface
*Number of connected Sensors: 1
Ratings
Power supply voltage 21.6 to 26.4 VDC (including ripple)
Insulation resistance Between all DC external terminals and case: 0.5 M min (at 250 VDC)
Current consumption
2.5 A max. : FQ2-S@@@@@@-@@@ and FQ-SDU@@
0.4 A max. : FQ2-S@@-@@@ and FQ-SDU@@
0.1 A max. : FQ-SDU@@ only
Environmental
immunity
Ambient temperature range Operating: 0 to 50ºC, Storage: -20 to 65ºC (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Ambient atmosphere No corrosive gas
Vibration resistance (destruction) 10 to 150 Hz, single amplitude: 0.35 mm, X/Y/Z directions, 8 min each, 10 times
Shock resistance (destruction) 150 m/s
2
3 times each in 6 directions (up, down, right, left, forward, and backward)
Degree of protection IEC 60529 IP20
Materials Case: PC + ABS, PC
Weight Approx. 150 g
Accessories included with Sensor Data Unit Instruction Manual
