FQ2
6
Ratings and Performance
Sensor [Inspection Model FQ2-S1/S2/S3 Series]
* The maximum number of registerable scenes depends on settings due to restrictions on memory.
Item
Single-function type
Standard type High-resolution type
Model
NPN FQ2-S10@@@@ FQ2-S20@@@@ FQ2-S30@@@@-08 FQ2-S30@@@@-08M FQ2-S30-13 FQ2-S30-13M
PNP FQ2-S15@@@@ FQ2-S25@@@@ FQ2-S35@@@@-08 FQ2-S35@@@@-08M FQ2-S35-13 FQ2-S35-13M
Field of view
Refer to Ordering Information on p.3. (Tolerance (field of view): ±10% max.)
Select a lens according to the field of view
and installation distance.
Refer to the optical chart on p.12.
Installation distance
Main
functions
Inspection items Shape search III, shape search II, search, sensitive search, area, color data, edge position, edge pitch, edge width, and labeling
Number of
simultaneous
measurements
132
Position compensation
Supported (360º Model position compensation, Edge position compensation, Linear correction)
Number of
registered scenes
8 * 32 *
Calibration Supported
input
Image processing
method
Real color Monochrome Real color Monochrome
Image filter
High dynamic range (HDR), image adjustment (Color Gray Filter, Weak smoothing, Strong smoothing, Dilate, Erosion, Median,
Extract edges, Extract horizontal edges, Extract vertical edges, Enhance edges, Background suppression), polarizing filter
(attachment), and white balance (Sensors with Color Cameras only), Brightness Correction
Image elements 1/3-inch color CMOS 1/2-inch color CMOS
1/2-inch
Monochrome CMOS
1/2-inch color CMOS
1/2-inch
Monochrome CMOS
Shutter
Built-in lighting ON: 1/250 to 1/50,000 s
Built-in lighting OFF: 1/1 to 1/50,000 s
Built-in lighting ON: 1/250 to 1/60,000 s
Built-in lighting OFF: 1/1 to 1/4,155 s
1/1 to 1/4,155 s
Processing resolution
752 × 480 928 × 828 1280 × 1024
Partial input function
Supported horizontally only. Supported horizontally and vertically
Image display
Zoom-in/Zoom-out/Fit, Rotating by 180º
Lens mounts --- C-mount
Lighting
Lighting method Pulse ---
Lighting color White ---
Data
logging
Measurement data
In Sensor: 1,000 items (If a Touch Finder is used, results can be saved up to the capacity of an SD card.)
Images In Sensor: 20 images (If a Touch Finder is used, images can be saved up to the capacity of an SD card.)
Auxiliary function
Statistical data, Test Measurements, I/O monitor, Password function, Simulation software, Sensor error history, Calibration,
Math (arithmetic, calculation functions, trigonometric functions, and logic functions)
Measurement trigger
External trigger (single or continuous)
Communications trigger (Ethernet TCP no-protocol, Ethernet UDP no-protocol, Ethernet FINS/TCP no-protocol, EtherNet/IP, PLC
Link, or PROFINET)
I/O
specificati
ons
Input signals
7 signals
• Single measurement input (TRIG)
• Control command input (IN0 to IN5)
Output signals
3 signals
• Control output (BUSY)
• Overall judgement output (OR)
• Error output (ERROR)
Note: The assignments of the three output signals (OUT0 to OUT2) can also be changed to the following:
• READY • RUN • STG (Strobe trigger)
• OR0 (Item0 judgement) to OR31 (Item31 judgement) • Exp.0 judgement to Exp.31 judgement
Ethernet specifications
100Base-TX/10Base-T
Communications Ethernet TCP no-protocol, Ethernet UDP no-protocol, Ethernet FINS/TCP no-protocol, EtherNet/IP, PLC Link, or PROFINET
I/O expansion --- --- Possible by connecting FQ-SDU1_ Sensor Data Unit. 11 inputs and 24 outputs
RS-232C --- --- Possible by connecting FQ-SDU2_ Sensor Data Unit. 8 inputs and 7 outputs
Ratings
Power supply voltage
21.6 to 26.4 VDC (including ripple)
Current consumption
2.4 A max. 0.3 A max.
Environme
ntal
immunity
Ambient
temperature
range
Operating: 0 to 50ºC
Storage: -25 to 65ºC
(with no icing or condensation)
Operating: 0 to 40ºC
Storage: -25 to 65ºC
(with no icing or condensation)
Ambient humidity
range
Operating and storage: 35% to 85% (with no condensation)
Ambient atmosphere
No corrosive gas
Vibration resistance
(destruction)
10 to 150 Hz, single amplitude: 0.35 mm, X/Y/Z directions
8 min each, 10 times
Shock resistance
(destruction)
150 m/s
2
3 times each in 6 direction (up, down, right, left, forward, and backward)
Degree of
protection
IEC 60529 IP67 (Except when Polarizing Filter Attachment is mounted
or connector cap is removed.)
IEC 60529 IP40
Materials
Sensor: PBT, PC, SUS
Mounting Bracket: PBT
Polarizing Filter Attachment: PBT, PC
Ethernet connector: Oil-resistance vinyl compound
I/O connector: Lead-free heat-resistant PVC
Cover: Zinc-plated steel,
Thickness: 0.6 mm
Case: Aluminum diecast alloy (ADC-12)
Mounting base: Polycarbonate ABS
Weight
Narrow View/Standard View:Approx.160 g
Wide View:Approx.150 g
Approx. 160 g without base,
Approx. 185 g with base
Accessories included
with sensor
Mounting Bracket (FQ-XL) (1)
Polarizing Filter Attachment (FQ-XF1) (1)
Instruction Manual, Member Registration Sheet
Mounting Base (FQ-XLC) (1)
Mounting Screw (M3 × 8mm) (4)
Instruction Manual, Member Registration Sheet
LED class Risk Group 2 (IEC62471) ---
Applicable standards EC Directive No.2004/108/EC and EN standard EN 61326-1
