A-58 Power Relay G7J
PCB Terminals
PCB Terminals (Bifurcated Contact)
W-bracket Screw Terminals
Screw Terminals (Bifurcated Contact)
Tab Terminals
Tab Terminals (Bifurcated Contact)
Consult your OMRON representative for details on models not men-
tioned in this document.
■ Accessories (Order Separately)
Application Examples
• Compressors for air conditioners and heater switching controllers.
• Switching controllers for power tools or motors.
• Lamp controls, motor drivers, and power supply switching control-
lers in copy machines, facsimile machines, and other office equip-
ment.
• Power controllers for packers or food processing equipment.
• Power controllers for inverters.
Contact form Rated voltage (V) Model
4PST-NO 24, 50, 100 to 120,
200 to 240 VAC
G7J-4A-P
12, 24, 48, 100 VDC
3PST-NO/
SPST-NC
24, 50, 100 to 120,
200 to 240 VAC
G7J-3A1B-P
12, 24, 48, 100 VDC
DPST-NO/DPST-
NC
24, 50, 100 to 120,
200 to 240 VAC
G7J-2A2B-P
12, 24, 48, 100 VDC
Contact form Rated voltage (V) Model
4PST-NO 200 to 240 VAC
24 VDC
G7J-4A-PZ
3PST-NO/
SPST-NC
12, 24 VDC G7J-3A1B-PZ
Contact form Rated voltage (V) Model
4PST-NO 24, 50, 100 to 120,
200 to 240 VAC
G7J-4A-B
12, 24, 48, 100 VDC
3PST-NO/
SPST-NC
24, 50, 100 to 120,
200 to 240 VAC
G7J-3A1B-B
12, 24, 48, 100 VDC
DPST-NO/
DPST-NC
24, 50, 100 to 120,
200 to 240 VAC
G7J-2A2B-B
12, 24, 48, 100 VDC
Contact form Rated voltage (V) Model
3PST-NO/
SPST-NC
200 to 240 VAC G7J-3A1B-BZ
6, 12, 24, 48, 100 VDC
Contact form Rated voltage (V) Model
4PST-NO 24, 50, 100 to 120,
200 to 240 VAC
G7J-4A-T
12, 24, 48, 100 VDC
3PST-NO/
SPST-NC
24, 50, 100 to 120,
200 to 240 VAC
G7J-3A1B-T
12, 24, 48, 100 VDC
DPST-NO/
DPST-NC
24, 50, 100 to 120,
200 to 240 VAC
G7J-2A2B-T
12, 24, 48, 100 VDC
Contact form Rated voltage (V) Model
4PST-NO 200 to 240 VAC G7J-4A-TZ
Name Model Applicable Relay
W-bracket R99-04 for G5F G7J-4A-B
G7J-3A1B-B
G7J-2A2B-B
G7J-4A-T
G7J-3A1B-T
G7J-2A2B-T
