A-64 Power Relay G7J
35±0.1
24
44 4.4
30
7
9
29
35
14
24
34
44
A2 A1 A2 A1 A2 A1
43
42 41 42 41
33 34 33
32 31
23 24 23 24 23
13 14 13 14 13
28
Terminal Arrangement/Internal Connections
Accessories (Order Separately)
R99-04 W-bracket (for G5F)
G7J-4A-P(B) (T) (Z) G7J-3A1B-P(B) (T) (Z) G7J-2A2B-P(B) (T)
The coil has no polarity.
Two, 4.5 dia.
Note: Terminals 43 and 44 of the
G7J-4A-P(B)(T)(Z) and
contacts 41 and 42 of the
G7J-3A1B-P(B)(T)(Z) are
bifurcated contacts.
Mounting Holes
Two, 4.5 dia. or M4
