G9SA
G-111G9SA
Specifications
Ratings
Power Input
Note: When an Expansion Unit is connected, the power consumption is increased by 2 VA/2 W max.
Inputs
Note: When an Expansion Unit is connected, the input current is increased by 30 mA max.
Contacts
Characteristics
Note: 1. The contact resistance was measured with 1 A at 5 VDC using the voltage-drop method.
2. The response time is the time it takes for the main contact to open after the input is turned OFF.
3. The insulation resistance was measured with 500 VDC at the same places that the dielectric strength was checked.
4. Weight shown is for 24-VAC/VDC type. For 100 to 240-VAC type, add approximately 20 g.
Item G9SA-301/TH301 G9SA-501 G9SA-321-T#
Power supply voltage
24 VAC/VDC:24 VAC, 50/60 Hz, or 24 VDC
100 to 240 VAC:100 to 240 VAC, 50/60 Hz
Operating voltage range 85% to 110% of rated power supply voltage
Power consumption
(See note.)
24 VAC/VDC: 1.8 VA/1.7 W max.
100 to 240 VAC: 9 VA max.
24 VAC/VDC: 2.8 VA/2.6 W max.
100 to 240 VAC: 11 VA max.
24 VAC/VDC: 3.5 VA/3.3 W max.
100 to 240 VAC: 12.5 VA max.
Item G9SA-301/321-T#/TH301 G9SA-501
Input current (See note.) 40 mA max. 60 mA max.
Item
G9SA-301/501/321-T#/TH301/EX301/EX031-T#
Resistive load (cos φ =1)
Rated load 250 VAC, 5 A
Rated carry current 5 A
Item G9SA-301/TH301 G9SA-501/321-T# G9SA-EX301/EX031-T#
Contact resistance (see note 1) 100 mΩ
Operating time 30 ms max. (not including bounce time)
Response time (see note 2) 10 ms max. (not including bounce time)
Insulation resistance (see note 3) 100 MΩ min. (at 500 VDC)
Dielectric
strength
Between different outputs
2,500 VAC, 50/60 Hz for 1 min
Between inputs and outputs
Between power inputs and outputs
Between power inputs and other inputs
(only for 100 to 240-V models)
Vibration resistance 10 to 55 Hz, 0.75-mm double amplitude
Shock
resistance
Destruction 300 m/s
2
Malfunction 100 m/s
2
Durability
Mechanical 5,000,000 operations min. (at approx. 7,200 operations/hr)
Electrical 100,000 operations min. (at approx. 1,800 operations/hr)
Minimum permissible load (reference value) 5 VDC, 1 mA
Ambient temperature
Operating:-25°C to 55°C (with no icing or condensation)
Storage:-25°C to 85°C (with no icing or condensation)
Ambient humidity
Operating:35% to 85%
Storage:35% to 85%
Terminal tightening torque 0.98 N·m
Weight (see note 4) Approx. 210 g Approx. 270 g
Approx. 130 g
Approved standards EN954-1, EN60204-1, EN574 (-TH301), UL508, CSA C22.2 No. 14
EMC
EMI: EN55011 group 1 class A
EMS: EN50082-2 group 1
F502-EN2-04.book Seite 111 Dienstag, 26. Juli 2005 5:48 17
